Moxa EDS-208A-MM-SC Industrial Ethernet Switch

Item NO.:
EDS-208A-MM-SC
Payment:
T/T
Price:
$295
Product Origin:
CHINA
Color:
NEW
Product weight:
0.02KG
Lead Time:
In stock

MOXA EDS-208A-MM-SC Industrial Ethernet Switch

The MOXA EDS-208A-MM-SC is an 8-port unmanaged industrial Ethernet switch featuring 6 × 10/100BaseT(X) RJ45 ports and 2 × 100BaseFX multimode fiber ports with SC connectors. It supports redundant 12/24/48 VDC power inputs and is designed for industrial automation and harsh environments.

Key Technical Specifications

Specification	Details
Brand	MOXA
Model	EDS-208A-MM-SC
Product Type	Unmanaged Industrial Ethernet Switch
Ethernet Ports	6 × 10/100BaseT(X) RJ45
Fiber Ports	2 × 100BaseFX Multimode SC
Fiber Type	Multimode
Fiber Wavelength	1300 nm
Typical Fiber Distance	Up to 4 km
Ethernet Standard	IEEE 802.3 / 802.3u / 802.3x
Duplex	Full/Half Duplex
Auto MDI/MDI-X	Yes
Switching Method	Store-and-Forward
MAC Table	2K
Packet Buffer	768 kbits
Power Input	12/24/48 VDC redundant dual inputs
Operating Voltage	9.6–60 VDC
Input Current	0.15 A @ 24 VDC
Power Connector	Removable 4-contact terminal block
Protection	Reverse Polarity & Overload Protection
Housing	Aluminum
Protection Rating	IP30
Mounting	DIN Rail / Wall Mount
Dimensions	50 × 114 × 70 mm
Weight	Approx. 275 g
Operating Temperature	-10 to +60 °C
Humidity	5–95% RH, non-condensing
Broadcast Storm Protection	DIP Switch Configurable

Advantages & Features

8-port industrial Ethernet switch with copper and fiber connectivity.
6 × RJ45 10/100 Mbps Ethernet ports.
2 × 100BaseFX multimode SC fiber ports.
Fiber transmission distance up to 4 km with the specified multimode configuration.
Redundant dual DC power inputs improve system availability.
Supports Auto MDI/MDI-X and automatic speed negotiation.
Compact aluminum housing with DIN-rail mounting.
Supports broadcast storm protection.
Designed for industrial, transportation, maritime, and hazardous-location applications; applicable certifications vary by model/configuration.

Typical Applications

Industrial automation networks
PLC and HMI communication
Factory Ethernet systems
Machine networking
Remote I/O networks
Fiber-optic industrial networks
Transportation and infrastructure systems
Maritime and industrial control environments

Important Precautions

The MM-SC version uses multimode SC fiber; do not confuse it with the single-mode SS-SC version.
The operating voltage is 9.6–60 VDC, with redundant 12/24/48 VDC inputs.
Use compatible multimode fiber and SC connectors.
IP30 protection does not provide protection against water or dust ingress comparable to IP65/IP67 equipment.
For hazardous-area installations, verify the exact certification requirements of the installation and the product's nameplate.
