AUTOMATION DIRECT D2-09BDC1-1 DirectLOGIC DL205 I/O Base

AUTOMATION DIRECT D2-09BDC1-1 DirectLOGIC DL205 I/O Base

Product Description

Detailed Parameters

1. Slot Configuration
   • 9 module slots (1 CPU slot, 1 power supply slot, and 7 I/O module slots).
   • Slot 1 is dedicated to the CPU module, Slot 2 to the power supply module, and Slots 3-9 for I/O module expansion.
2. Power Specifications
   • 24VDC power input, compatible with D2 series power modules (e.g., D2-PS1 or D2-PS2).
   • Backplane bus provides 5VDC and 24VDC outputs to power connected modules.
3. Communication Features
   • High-speed internal backplane bus with data transfer rate ≥1Mbps.
   • Daisy-chain connection support allows up to 5 bases (45 I/O modules total) via extension cables.
4. Mechanical Characteristics
   • Dimensions: 297mm (L) × 100mm (W) × 75mm (H).
   • Weight: Approximately 650g (without modules).
   • Mounting: Standard DIN rail (35mm) mounting, horizontal or vertical orientation supported.
5. Environmental Parameters
   • Operating Temperature: 0°C to 55°C.
   • Storage Temperature: -20°C to 70°C.
   • Humidity: 5% to 95% (non-condensing).
   • Protection Class: IP20 (base unit only; modules require separate evaluation).
6. Certifications
   • UL, CSA, CE certified, compliant with industrial control equipment safety standards.

Product Advantages and Features

1. Modular Design
   • Flexible Configuration: 9 slots allow custom combinations of I/O modules for digital, analog, and communication functions.
   • Hot-Swap Support: Replace or add modules without powering down the system, minimizing downtime and improving maintenance efficiency.
2. Electrical Isolation and Noise Immunity
   • Inter-module Isolation: Optocoupler isolation between slots reduces electromagnetic interference (EMI) and radio-frequency interference (RFI), ensuring reliable signal transmission.
   • Power Protection: Built-in overvoltage and overcurrent protection circuits safeguard modules from power fluctuations.
3. High-Speed Data Transfer
   • Backplane bus uses high-speed protocol for real-time data exchange between modules, meeting response requirements for complex industrial control applications.
4. Expansion Capability
   • Daisy-Chain Support: Connect up to 5 bases via extension cables (max. 45 I/O modules), suitable for medium to large control systems.
5. Ease of Installation
   • Standard DIN rail mounting without special tools, supports horizontal or vertical installation for flexible control cabinet layouts.
   • Secure Locking Mechanism: Spring-loaded clips ensure modules remain firmly connected, preventing loosening due to vibration or shock.

Applications

1. Industrial Automation Production Lines
   • Connects PLCs to field devices (sensors, actuators, motor drives, etc.) for automated process control.
2. Machine Tool Control
   • Serves as a centralized I/O hub in machine tools, packaging machinery, and logistics equipment to coordinate operations.
3. Process Control
   • Ideal for chemical, food processing, and water treatment industries, collecting analog signals (temperature, pressure, flow) and outputting control commands.
4. Energy Management Systems
   • Connects power monitoring devices and smart meters for energy data acquisition and optimization.
5. Building Automation
   • Functions as an expansion base for DDC (Direct Digital Controller) systems in smart buildings, integrating lighting, HVAC, and security systems.

Precautions

1. Power Connection
   • Use only 24VDC power modules within the specified voltage range (typically 20.4V to 28.8V).
   • Ensure total power consumption does not exceed the rated output of the power module when cascading multiple bases.
2. Module Installation
   • Always disconnect power before installing or removing modules to prevent electrical shock or damage.
   • Verify modules are fully seated and locked; incomplete insertion may cause communication failures or signal instability.
3. Expansion Limitations
   • Daisy-chain extension cables must not exceed 1 meter between bases, and total base count is limited to 5.
   • Avoid mixing high-speed and low-speed modules on the same base to maintain system performance.
4. Environmental Requirements
   • Avoid use in environments with strong magnetic fields, moisture, or corrosive gases. Use protective enclosures or ventilation if necessary.
   • If operating temperature exceeds 55°C, consider additional cooling or derate module performance.
5. Communication Configuration
   • Assign unique base addresses (0-4) via software when configuring multiple bases to prevent address conflicts.
   • Ensure module types selected in DirectSoft software match physically installed modules.
6. Troubleshooting
   • Check extension cable connections if communication issues arise; try re-seating or replacing cables.
   • Use module LED indicators to diagnose faults (e.g., power failure, communication errors) as described in the product manual.

The structure and details of the product：
