AUTOMATION DIRECT D2-08TA Discrete Output Module

AUTOMATION DIRECT D2-08TA Discrete Output Module

Product Description

Detailed Parameters

1. Output Channels
   • Quantity: 8 independent output channels, which can control 8 external loads simultaneously. This multi-channel design allows centralized control of multiple devices on a single module, reducing the number of modules required in the system, thereby lowering costs and wiring complexity.
   • Number of Points per Common Terminal: 8 output points share 1 common terminal. This configuration simplifies wiring and facilitates unified control of a group of related devices.
2. Load Driving Capacity
   • Single Channel Load Current: Each output point can withstand a current of 0.5A, which is sufficient to drive most common industrial loads. For example, the coil operating current of small AC contactors is generally a few hundred milliamperes, and the single-channel output capacity of the D2-08TA can fully meet the driving requirements.
   • Total Current of Common Terminal: The common terminal can withstand a total current of 4A, ensuring that the module can stably supply sufficient current to the loads when multiple output points are working simultaneously.
3. Operating Voltage
   • Input Voltage Range: Supports a wide voltage input range of 24-240VAC. This feature enables the module to adapt to power supply voltages in different regions and application scenarios, whether in a standard 220VAC industrial power supply environment or in some special occasions using 24VAC safety voltage, it can work normally.
   • Voltage Adaptability: It can work stably within a wide range of voltage fluctuations, reducing the risk of equipment failure caused by unstable voltage and improving the reliability of the system.
4. Output Type: Adopts relay output mode. Relay output has good electrical isolation performance, which can effectively isolate the internal circuit of the PLC from the external load circuit, avoiding external interference from affecting the PLC system. At the same time, relay output can switch AC or DC loads, with strong versatility, suitable for various types of industrial equipment.
5. Response Time
   • Turn-on Response Time: Approximately 12ms, which is the time from when the PLC sends an output signal to when the relay contacts close and the external load is connected. This response time is fast enough in most industrial automation applications to meet the requirements of real-time control of equipment.
   • Turn-off Response Time: Approximately 10ms, the time from when the PLC cancels the output signal to when the relay contacts open and the external load is disconnected. The short turn-off response time helps to stop the equipment operation quickly, improving the control accuracy and safety of the system.
6. Physical Characteristics
   • Dimensions: The compact design allows it to be easily installed in limited control cabinet space. The specific dimensions are [length] × [width] × [height], which is convenient for integration into various industrial control systems.
   • Weight: The module is light in weight, facilitating installation and maintenance, and reducing the overall weight burden of the control cabinet.
   • Mounting Method: Supports standard DIN rail mounting. The installation process is simple and quick, and the module can be firmly fixed on the DIN rail in the control cabinet through rail clips.
   • Terminal Type: Equipped with a detachable terminal block, which is convenient for users to perform wiring operations. During installation and maintenance, users can connect the cables to the terminal block in advance, and then insert the terminal block into the module, which greatly improves work efficiency. At the same time, the detachable terminal block also facilitates the quick transfer of cables to the new module when the module needs to be replaced.
7. Other Characteristics
   • Status Indication: The module is equipped with logic side status indicators. Through indicators of different colors, the working status of each output channel can be intuitively understood. For example, the indicator light being on indicates that the channel is in the output on state, which is convenient for users to carry out fault 排查 and system debugging.
   • Fuse Protection: Each common terminal is equipped with a fuse. When abnormal situations such as short circuit or overload occur in the load, the fuse will blow quickly to cut off the circuit, protecting the module and external equipment from damage. The rated current of the fuse is [specific current value], and users can choose a suitable fuse for replacement according to the actual load situation.

Product Advantages and Features

1. High Versatility: The wide range of working voltages and relay output types enable it to adapt to various types and specifications of AC loads, whether small equipment or large industrial machinery, suitable application scenarios can be found.
2. Reliable Performance: Good electrical isolation performance and fuse protection mechanism effectively improve the anti-interference ability and safety of the module, reduce system downtime caused by electrical faults, and ensure the continuity of industrial production.
3. Easy Installation and Maintenance: The compact design, standard DIN rail mounting method, and detachable terminal block make the installation and maintenance of the module simple and efficient, reducing the user's use cost and technical threshold.
4. Cost-Effective: The 8-channel design and reasonable price positioning provide users with a cost-effective solution while meeting their control needs, especially suitable for small and medium-sized automation projects sensitive to cost.

Application Fields

1. Industrial Automation Production Lines: Used to control the operation of various equipment on the production line, such as the start-stop of conveyor motors, the opening and closing of pneumatic valves, the action of product sorting devices, etc., to realize the automatic control of the production process.
2. Mechanical Equipment Control: In mechanical equipment such as machine tools, packaging machines, and printing machines, control various actuators of the equipment, such as controlling the forward and reverse rotation of motors, the engagement and disengagement of clutches, etc., to ensure the normal operation and precise operation of mechanical equipment.
3. Lighting and HVAC Systems: In the lighting system of buildings, control the switching of lights in different areas to realize functions such as timed lighting and induction lighting; in the HVAC (Heating, Ventilation, and Air Conditioning) system, control the operation of equipment such as fans, water pumps, and valves to adjust indoor temperature, humidity, and air quality.
4. Logistics and Warehousing Equipment: Used to control the operation of equipment such as stackers and shuttle cars in automated three-dimensional warehouses, as well as the actions of sorting equipment and elevators on logistics conveyor lines, improving the automation level and operation efficiency of logistics and warehousing systems.
5. Energy Management Systems: In energy management systems, control the switching of power equipment, such as controlling the start and stop of backup generators, switching the power supply between different power sources, etc., to realize the reasonable distribution and effective management of energy.
