AutomationDirect EA7-S6M HMI Operator Panel

EA7-S6M
EA7-S6M

AutomationDirect EA7-S6M HMI Operator Panel

AutomationDirect EA7-S6M HMI Operator Panel

  • Item NO.:

    EA7-S6M

  • Payment:

    T/T

  • Price:

    $295

  • Product Origin:

    CHINA

  • Color:

    NEW

  • Product weight:

    0.02KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                          • AutomationDirect EA7-S6M C-more HMI Operator Panel

                                                                                                            The AutomationDirect EA7-S6M is a C-more EA7 Series 6-inch HMI/operator panel with a 5.7-inch viewable grayscale STN touchscreen. It features 320 × 240 QVGA resolution, 24 VDC power, Ethernet, USB, serial communication, and CompactFlash support. AutomationDirect lists this model as discontinued.

                                                                                                            Key Technical Specifications

                                                                                                            Specification Details
                                                                                                            Brand AutomationDirect
                                                                                                            Model EA7-S6M
                                                                                                            Product Type C-more HMI Operator Panel
                                                                                                            Series EA7
                                                                                                            Display Type 5.7" STN Grayscale LCD
                                                                                                            Display Size 6" class
                                                                                                            Color Scale 15 shades of gray
                                                                                                            Resolution 320 × 240 pixels (QVGA)
                                                                                                            Viewing Area 4.54" × 3.40" (115.2 × 86.4 mm)
                                                                                                            Touchscreen Analog Resistive, 10-bit
                                                                                                            CPU 32-bit RISC, 333 MHz
                                                                                                            User Memory 10 MB
                                                                                                            Operating Voltage 24 VDC
                                                                                                            Operating Range 20.4–28.8 VDC
                                                                                                            Communication 1 × Serial, 1 × Ethernet
                                                                                                            USB 2 × USB
                                                                                                            Memory Card CompactFlash supported
                                                                                                            Backlight Non-replaceable
                                                                                                            Backlight Life Approx. 50,000 hours
                                                                                                            Protection NEMA 4/4X, IP65 when properly mounted
                                                                                                            Mounting Panel Mount
                                                                                                            Status Discontinued



                                                                                                            Advantages & Features

                                                                                                            • 5.7-inch grayscale STN touchscreen.
                                                                                                            • 320 × 240 QVGA resolution.
                                                                                                            • Built-in Ethernet and USB connectivity.
                                                                                                            • Supports CompactFlash memory cards.
                                                                                                            • Built-in serial communication interface.
                                                                                                            • 10 MB user/project memory.
                                                                                                            • 24 VDC industrial power supply.
                                                                                                            • Analog resistive touchscreen suitable for industrial operator interaction.
                                                                                                            • NEMA 4/4X and IP65 protection when correctly panel-mounted.

                                                                                                            Typical Applications

                                                                                                            • PLC operator interfaces
                                                                                                            • Machine monitoring and control
                                                                                                            • Factory automation
                                                                                                            • Packaging machinery
                                                                                                            • Conveyor systems
                                                                                                            • Production equipment
                                                                                                            • Industrial process monitoring

The structure and details of the product：
