AutomationDirect EA1-S3ML HMI Operator Panel

EA1-S3ML
EA1-S3ML

AutomationDirect EA1-S3ML HMI Operator Panel

AutomationDirect EA1-S3ML HMI Operator Panel

  • Item NO.:

    EA1-S3ML

  • Payment:

    T/T

  • Price:

    $295

  • Product Origin:

    CHINA

  • Color:

    NEW

  • Product weight:

    0.02KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                •
                                                                                              • https://images.openai.com/static-rsc-4/luYcPFrFqrtNqwSiFImXrH98naSm4yw21VMnpQGn1cDyPJe-OdkRxmb4_Khp5M_HLjosg4CyqDJ-l9hX0dMpGbDlalaK28oVza0EsBbtuVV-52eJOsXyLdbl3KuOAV-knF6F3ykXI0yoG5eAjG0J04WlaTh9n3oUND_5IvIT1vHIGrR84-r8h8dBmrInM06K?purpose=fullsize

                                                                                              • Product Overview

                                                                                                The AutomationDirect EA1-S3ML is a C-more Micro EA1 Series 3.1-inch touchscreen HMI operator panel featuring a monochrome STN LCD, analog resistive touchscreen, five programmable function keys, and an RJ12 serial communication port. It is designed for compact PLC and machine-control applications.

                                                                                                Key Technical Specifications

                                                                                                Parameter Specification
                                                                                                Brand AutomationDirect
                                                                                                Series C-more Micro EA1
                                                                                                Model EA1-S3ML
                                                                                                Product Type HMI Operator Panel
                                                                                                Display 3.1-inch Monochrome STN LCD
                                                                                                Resolution 128 × 64 pixels
                                                                                                Touchscreen Analog Resistive, Single Touch
                                                                                                Backlight LED
                                                                                                Backlight Colors Red, Green, Amber, Lime, Yellow
                                                                                                Function Keys 5 programmable keys
                                                                                                User Memory 768 KB
                                                                                                Maximum Screens Up to 999
                                                                                                Communication 1 × RS-232 RJ12
                                                                                                External Power 5 VDC
                                                                                                Alternative Power 12–24 VDC with optional adapter
                                                                                                Protection NEMA 4/4X, IP65
                                                                                                Operating Temperature 0–50°C
                                                                                                Installation Panel Mount
                                                                                                Application Indoor



                                                                                                Advantages & Features

                                                                                                • Compact 3.1-inch touchscreen HMI
                                                                                                • Monochrome graphical display with 128 × 64 resolution
                                                                                                • Five programmable function keys with LED indicators
                                                                                                • Five selectable backlight colors
                                                                                                • 768 KB user memory
                                                                                                • Supports up to 999 screens depending on project size
                                                                                                • Multiple PLC communication protocols
                                                                                                • Rugged NEMA 4/4X and IP65 panel-mount design
                                                                                                • Suitable for space-limited control panels

                                                                                                Typical Applications

                                                                                                • PLC monitoring and control
                                                                                                • Machine automation
                                                                                                • Packaging equipment
                                                                                                • Factory automation
                                                                                                • Production lines
                                                                                                • Material handling
                                                                                                • Industrial equipment monitoring
                                                                                                • Compact operator-control panels

                                                                                                Important Notes

                                                                                                • The EA1-S3ML requires 5 VDC when powered through its serial connection; an optional adapter can provide 12–24 VDC.
                                                                                                • Use the EA-MG-PGM-CBL for programming.
                                                                                                • The touchscreen is designed for single-touch operation.
                                                                                                • IP65/NEMA 4/4X protection depends on correct panel installation.
                                                                                                • The model has been discontinued; AutomationDirect lists EA3-S3ML as a comparable replacement.
