AutomationDirect D4-450DC-1 PLC CPU Module

Item NO.:
D4-450DC-1
Payment:
T/T
Price:
$295
Product Origin:
CHINA
Color:
NEW
Product weight:
0.02KG
Lead Time:
In stock

Product Overview

The AutomationDirect D4-450DC-1 is a DirectLOGIC DL405 DL450 CPU module designed for demanding PLC control and industrial automation applications. It features 7.5K words of built-in ladder memory, four built-in communication ports, floating-point math, and support for up to 16 PID loops. It operates from an external 24 VDC power supply.

Key Technical Specifications

Parameter	Specification
Brand	AutomationDirect
Series	DirectLOGIC DL405 / DL450
Model	D4-450DC-1
Product Type	PLC CPU Module
Power Supply	24 VDC
Input Voltage Range	20–28 VDC
Ladder Memory	7.5K words Flash
Total Memory	Approx. 30.8K words
PID Loops	Up to 16
Communication Ports	4 built-in ports
Port 1	RS-232C / DB15
Port 2	RS-232C / RJ12
Ports 3 & 4	RS-232 / RS-422 / DB25
Protocols	K-sequence, DirectNET, Modbus
Programming	DirectSOFT
Math	IEEE floating-point / trigonometric functions
Programming Language	RLL / RLLPLUS
Battery	Battery backup included
Installation	DL405 PLC base

The four communication ports support programming, operator-interface connections, DirectNET/Modbus networking and ASCII applications.

Advantages & Features

High-performance DL450 PLC CPU
Up to 16 integrated PID control loops
Built-in floating-point mathematical processing
Four integrated serial communication ports
Supports DirectNET and Modbus communication
7.5K words of built-in Flash ladder memory
Supports optional memory cartridges for expanded ladder memory
Suitable for complex machine and process-control applications
Built-in power supply and battery backup

Typical Applications

Factory automation
Process control
Machine control
Packaging equipment
Material handling systems
Production lines
HVAC and building automation
Motion and temperature control systems
Industrial data acquisition and supervisory control

Important Notes

The D4-450DC-1 requires 24 VDC external power; it is different from the AC-powered D4-450 and 125 VDC D4-450DC-2.
This model is discontinued; AutomationDirect lists D4-454DC-1 as a replacement.
The CPU includes a battery, so battery condition should be checked on used/old-stock units.
Confirm the PLC base, memory configuration, communication requirements, and installed specialty modules before replacement.
Follow proper ESD precautions when handling the CPU.
