AUTOMATIONDIRECT D2-32TD1 Digital Output Module

Product Overview

Model: D2-32TD1
Series: DirectLOGIC DL205 PLC
Manufacturer: AutomationDirect

The AUTOMATIONDIRECT D2-32TD1 is a 32-point DC Digital Output Module designed for the DirectLOGIC DL205 PLC system. It provides reliable transistor output control for industrial devices such as relays, solenoid valves, indicators, and actuators. The module uses a 12–24VDC sinking output design and is suitable for high-speed switching applications.

Technical Specifications

• Product Type: Digital Output Module
• Model: D2-32TD1
• Series: DirectLOGIC DL205
• Output Points: 32 channels
• Output Type: DC transistor output (NPN open collector)
• Output Mode: Sinking output
• Rated Voltage: 12–24 VDC
• Maximum Voltage: 30 VDC
• Output Current:
  • 0.1 A per point
  • 3.2 A maximum per module
• Output Groups: 4 isolated commons
• Points per Common: 8 points
• ON Voltage Drop: Max. 0.5 VDC @ 0.1A
• Leakage Current: Max. 0.1 mA @ 30VDC
• Response Time: Approx. 0.5 ms ON/OFF
• Power Requirement: 5VDC / 350mA from PLC base
• Terminal Connection: Removable 40-pin connector
• Compatible System: AutomationDirect DirectLOGIC DL205 PLC
• Programming Software: DirectSOFT

Advantages & Features

• 32-Channel Output Control
  Provides multiple digital outputs for controlling industrial devices.
• Fast Switching Performance
  Transistor output design supports high-speed switching applications.
• Electrical Isolation Design
  Four isolated commons help reduce interference and improve system reliability.
• Compact PLC Expansion
  Expands DL205 PLC output capacity while saving control cabinet space.
• Reliable Industrial Operation
  Designed for continuous operation in factory automation environments.
• Flexible Device Control
  Suitable for controlling relays, valves, lamps, and other DC loads.

Applications

• Industrial Automation Systems
• Machine Control Equipment
• Packaging Machinery
• Conveyor Systems
• Solenoid Valve Control
• Production Line Automation
• Material Handling Systems
• Factory Control Systems

Precautions

• Verify compatibility with DirectLOGIC DL205 PLC base before installation.
• Confirm 12–24VDC output requirements.
• Check current consumption of connected devices.
• Use proper protection for inductive loads such as solenoid valves and relays.
• Ensure correct sinking output wiring configuration.
• Disconnect PLC power before installation or replacement.
• Keep wiring away from high-voltage interference sources.
