AUTOMATIONDIRECT D0-06DR-D PLC CPU Module

Product Overview

Model: D0-06DR-D
Series: DirectLOGIC DL06 PLC
Manufacturer: AutomationDirect

The AUTOMATIONDIRECT D0-06DR-D is an integrated PLC CPU module from the DirectLOGIC DL06 series. It combines CPU processing, digital inputs, relay outputs, communication ports, and expansion capability into a compact PLC controller. It is designed for small to medium industrial automation applications requiring reliable logic control and flexible communication.

Technical Specifications

• Product Type: PLC CPU / Programmable Logic Controller
• Model: D0-06DR-D
• Series: DirectLOGIC DL06
• CPU Type: Integrated PLC Controller
• Power Supply: 12–24 VDC
• Digital Inputs: 20 points DC input
• Input Type: Sinking / Sourcing
• Digital Outputs: 16 points Relay Output
• Relay Output Rating: 2A per point
• Input Voltage: 12–24 VDC
• Output Voltage Range: 6–240 VAC / 6–24 VDC
• Program Memory: 7K words ladder memory
• Total Memory: 14.8K words
• PID Control: Supports up to 8 PID loops
• Communication Ports:
  • 1 × RS-232 (RJ12) programming port
  • 1 × RS-232 / RS-422 / RS-485 port
• Communication Protocols:
  • DirectNET
  • MODBUS RTU
  • ASCII
  • K-sequence
• Expansion Capability: Supports up to 4 expansion modules
• Programming Software: DirectSOFT
• Battery Backup: Supported (D2-BAT-1)
• High-Speed Counter: Supports high-speed counting functions

Advantages & Features

• Integrated PLC Design
  Combines CPU, inputs, outputs, and communication functions into one compact controller.
• Flexible I/O Capability
  Built-in 20 digital inputs and 16 relay outputs meet many small automation requirements.
• Multiple Communication Options
  Supports RS-232/RS-485 communication for connection with HMIs, drives, and other devices.
• Reliable Relay Outputs
  Relay output design supports both AC and DC load control.
• Compact Installation
  Space-saving design is suitable for control cabinets with limited installation space.
• Easy Programming and Maintenance
  Compatible with DirectSOFT programming software for convenient configuration.

Applications

• Industrial Automation Systems
• Machine Control Equipment
• Packaging Machinery
• Conveyor Control Systems
• Assembly Line Equipment
• Building Automation
• Process Monitoring Systems
• Small Production Machines

Precautions

• Verify 12–24VDC power supply before installation.
• Confirm input/output wiring configuration before connection.
• Check relay output load current to avoid overload.
• Use proper grounding to reduce electrical interference.
• Backup PLC programs before replacing the CPU.
• Install battery backup if required for data retention.
• Disconnect power before wiring or module replacement.
