Product Description

Detailed Parameters

1. Input Specifications
   • Number of Input Points: 16 independent discrete input channels.
   • Input Voltage Range: 120VAC (nominal), with a tolerance of ±15% (102-138VAC).
   • Input Type: AC voltage detection, compatible with inductive/capacitive proximity sensors, pushbuttons, and relay contacts.
   • Common Terminal Configuration: 4 isolated common terminals (each group of 4 input points shares 1 common terminal), reducing interference between channels.
2. Electrical Characteristics
   • Input Current: 8-12mA per channel at 120VAC.
   • Response Time: ≤5ms (on/off), meeting the needs of general automation control.
   • Isolation Voltage: 250VAC between channels and common terminals, enhancing anti-interference performance.
   • Noise Immunity: Complies with IEC 61000-4-4 standards for electrostatic discharge (ESD) and surge protection.
3. Power Supply and Compatibility
   • Power Supply: Derived from the PLC base (5VDC, maximum current 150mA), no additional power supply required.
   • PLC Compatibility: Seamlessly integrates with DirectLogic DL205 series PLCs, requiring a compatible base (e.g., D2-09BDC).
   • Terminal Type: Removable screw terminals for easy wiring and maintenance.
4. Environmental Parameters
   • Operating Temperature: 0°C to 55°C (32°F to 131°F).
   • Storage Temperature: -20°C to 70°C (-4°F to 158°F).
   • Humidity: 5%-95% RH (non-condensing).
   • Protection Class: IP20 (only suitable for installation in control cabinets).
5. Physical Features
   • Dimensions: 110mm (length) × 76mm (width) × 30mm (height).
   • Weight: Approximately 120g.
   • Status Indicators: Each channel is equipped with an LED indicator (green) to visually display the input signal status.

Product Advantages and Features

1. High Channel Density: 16 input channels integrated into a compact module, saving space in the control cabinet and reducing the number of modules required, thus lowering system costs.
2. Wide AC Voltage Compatibility: Supports 120VAC input, eliminating the need for additional voltage conversion devices in AC-powered industrial environments, simplifying system wiring.
3. Group Isolation Design: 4 isolated common terminals effectively reduce electromagnetic interference (EMI) between channels, ensuring stable signal collection in complex industrial environments.
4. Industrial-Grade Reliability: Adopts industrial-grade components and surge protection designs, ensuring stable operation in harsh environments such as high noise and temperature fluctuations.
5. Easy Installation and Maintenance: Plug-and-play integration with DirectLogic DL205 series PLCs; removable terminals simplify wiring, and per-channel LED indicators facilitate quick troubleshooting of signal status.

Application Areas

1. Industrial Automation Production Lines: Collects status signals from conveyor sensors, limit switches, and safety interlocks to provide real-time feedback for production process control.
2. Mechanical Equipment Control: Connects to photoelectric sensors, emergency stop buttons, and travel switches of machine tools, packaging machines, and printing presses to monitor equipment operation status.
3. HVAC and Building Automation: Collects signals from valve position switches, pressure switches, and temperature control contacts to realize linkage control of building equipment.
4. Material Handling Systems: Integrates with proximity sensors and in-place switches of stackers and conveyor lines to achieve precise control of logistics and warehousing equipment.
5. Power Distribution Monitoring: Connects to auxiliary contact signals of circuit breakers and contactors in power distribution systems to monitor the on/off status of electrical equipment.

Precautions

1. Power Connection:
   • The input signal voltage must be within the 102-138VAC range; avoid overvoltage (exceeding 138VAC) to prevent module damage.
   • Ensure the polarity of the common terminal wiring matches the external sensor power supply to avoid signal distortion or non-response.
2. Wiring Requirements:
   • Use shielded cables for input signal lines, and avoid parallel routing with high-voltage power cables to reduce electromagnetic interference.
   • Turn off the system power before wiring; tighten terminal screws to prevent poor contact and signal loss.
3. Environmental Requirements:
   • Install the module in a well-ventilated control cabinet, avoiding exposure to dust, moisture, corrosive gases, or direct sunlight.
   • If the ambient temperature exceeds 55°C, take cooling measures (such as installing fans) to prevent performance degradation.
4. Compatibility Check:
   • Confirm that the PLC base (e.g., D2-09BDC) supports the D2-16NA module and that the base’s power supply capacity meets the module’s requirements (≤150mA at 5VDC).
5. Maintenance Notes:
   • Regularly check the tightness of terminal connections and the status of LED indicators; clean the module surface with a dry cloth to prevent dust accumulation.
   • When replacing the module, ensure the system is powered off to avoid damage to the PLC or module due to hot swapping (the module does not support hot swapping).
