Phoenix Contact 2966786 Relay Module

Phoenix Contact 2966786 Relay Module

Product Description

The Phoenix Contact 2966786 is a PLC-INTERFACE continuous plug-in bridge accessory used with Phoenix Contact PLC relay modules. It provides common potential distribution between multiple relay modules, simplifying control cabinet wiring and improving installation efficiency. It is not a relay itself, but an accessory component for PLC relay interface systems.

Technical Specifications

• Brand: Phoenix Contact
• Model: 2966786
• Product Type: Continuous Plug-in Bridge / Relay Module Accessory
• Series: PLC-INTERFACE
• Model Name: FBST 500-PLC RD
• Function: Power distribution bridge between relay modules
• Length: 500 mm
• Color: Red
• Maximum Current Carrying Capacity: 32 A
• Mounting: Plug-in connection for PLC relay terminals
• Application: DIN rail control cabinet wiring systems

Advantages & Features

• Simplifies wiring between multiple relay modules
• Reduces installation time and wiring complexity
• Provides reliable power distribution connection
• Compact design for PLC interface systems
• Improves control cabinet organization
• Easy installation and replacement
• Suitable for industrial automation applications

Applications

• PLC control cabinets
• Industrial automation systems
• Relay interface assemblies
• Machine control systems
• Process automation equipment
• Electrical distribution panels

Notes / Precautions

• Confirm compatibility with the specific Phoenix Contact PLC-INTERFACE relay modules before installation
• Check bridge length and required number of connection points
• Do not exceed maximum current rating
• Ensure correct installation direction and secure connection
• Disconnect power before installation or maintenance
