Phoenix Contact 2967345 Relay Module

Phoenix Contact 2967345 Relay Module

Product Description

The Phoenix Contact 2967345 (PLC-RSP-24DC/1/ACT) is a PLC-INTERFACE relay module designed for industrial automation control systems. It combines a relay base terminal and plug-in miniature relay, providing electrical isolation and reliable switching between PLC control signals and field devices. It is widely used for output signal switching in control cabinets.

Technical Specifications

• Brand: Phoenix Contact
• Model: 2967345
• Product Type: Relay Module
• Series: PLC-INTERFACE
• Model Name: PLC-RSP-24DC/1/ACT
• Function: Output switching / signal isolation
• Input Voltage: 24 V DC
• Input Voltage Range: 18.5–33.6 V DC
• Input Current: Approx. 9 mA
• Contact Type: 1 × Normally Open (NO) contact
• Contact Material: AgSnO
• Maximum Switching Voltage: 250 V AC/DC
• Continuous Current: 6 A
• Response Time: Approx. 5 ms
• Release Time: Approx. 8 ms
• Mounting: DIN rail mounting (NS 35)
• Protection Rating: IP20
• Dimensions: 6.2 × 80 × 94 mm
• Operating Temperature: -40°C to +60°C
• Connection Type: Spring-cage connection

Advantages & Features

• Provides reliable electrical isolation between PLC and field devices
• Compact 6.2 mm slim design saves cabinet space
• Integrated relay and terminal design simplifies installation
• Fast switching response for industrial control applications
• Supports DIN rail mounting for easy maintenance
• High mechanical service life up to 20 million cycles
• Reverse polarity and protection functions improve reliability
• Suitable for continuous industrial operation

Applications

• Industrial automation systems
• PLC output interface circuits
• Control cabinet signal switching
• Machine control equipment
• Motor and actuator control
• Process automation systems
• Manufacturing production lines

Notes / Precautions

• Confirm input voltage and relay contact rating before installation
• Check load type and switching current requirements
• Ensure correct wiring of coil and contact terminals
• Avoid exceeding maximum switching capacity
• Install in a suitable control cabinet environment
• Disconnect power before maintenance or replacement
