Phoenix Contact 2966692 Relay Module

Phoenix Contact 2966692 Relay Module

Product Description

The Phoenix Contact 2966692 is a PLC-INTERFACE Relay Module designed for industrial automation and control cabinet applications. It provides electrical isolation and reliable signal switching between PLC outputs and field devices, helping protect control systems and simplify industrial wiring.

Technical Specifications

• Brand: Phoenix Contact
• Model: 2966692
• Product Type: Relay Module
• Series: PLC-INTERFACE
• Function: Signal isolation and switching
• Input Voltage: 24 V DC (configuration dependent)
• Relay Type: Plug-in miniature relay
• Contact Type: Changeover contact (SPDT, configuration dependent)
• Switching Voltage: Up to 250 V AC/DC (model dependent)
• Mounting: DIN rail mounting
• Protection Rating: IP20
• Connection Type: Screw / Push-in terminal (version dependent)
• Application: PLC interface and industrial control systems

Advantages & Features

• Provides reliable electrical isolation between PLC and field devices
• Protects PLC outputs from high-load switching circuits
• Compact modular design saves control cabinet space
• Easy installation and replacement with plug-in relay design
• High switching reliability and long service life
• Suitable for continuous industrial operation
• Improves system maintenance efficiency

Applications

• PLC control systems
• Industrial automation equipment
• Machine control cabinets
• Motor and actuator control
• Process automation systems
• Manufacturing production lines
• DCS interface applications

Notes / Precautions

• Verify coil voltage and contact rating before installation
• Confirm relay compatibility with the PLC interface system
• Check load type and switching current requirements
• Ensure correct terminal wiring
• Avoid exceeding maximum switching capacity
• Disconnect power before maintenance or replacement
