Phoenix Contact MACX MCR-SL-RPSSI-I-UP Signal Conditioner

Phoenix Contact MACX MCR-SL-RPSSI-I-UP Signal Conditioner

Product Description

The Phoenix Contact MACX MCR-SL-RPSSI-I-UP is a Repeater Power Supply / Signal Conditioner from the MACX Analog series. It is designed for supplying and isolating 2-wire and 4-wire transmitters, while transmitting 0/4–20 mA analog signals with HART communication transparency. It provides reliable signal conditioning and electrical isolation for industrial process control systems.

Technical Specifications

• Brand: Phoenix Contact
• Model: MACX MCR-SL-RPSSI-I-UP
• Product Type: Signal Conditioner / Repeater Power Supply
• Series: MACX Analog
• Application: Analog Signal Input
• Channels: 1 Channel
• Input Signal:
  • 0/4–20 mA
  • Supports powered and unpowered transmitters
• Output Signal:
  • 0/4–20 mA
  • 0/1–5 V (selectable by DIP switch)
• Communication: HART transparent
• Power Supply:
  • 24 V AC/DC to 230 V AC/DC
• Isolation:
  • 3-way electrical isolation (input/output/power supply)
• Transmission Error: <0.1% of final value
• Response Time: <600 μs (4–20 mA step signal)
• Mounting: DIN rail mounting
• Protection Rating: IP20
• Operating Temperature: -40°C to +60°C
• Connection: Screw terminal connection

Advantages & Features

• Provides reliable analog signal isolation and conversion
• Supports HART communication without signal interruption
• Protects PLC/DCS analog inputs from electrical interference
• 3-way electrical isolation improves system safety
• Wide-range power supply supports flexible installation
• High accuracy and fast signal response
• Supports SIL 2 safety applications
• Compact DIN rail design saves cabinet space

Applications

• Process automation systems
• Oil & gas industry
• Chemical plants
• Power generation systems
• Petrochemical facilities
• DCS and PLC control cabinets
• Industrial transmitter signal isolation systems

Notes / Precautions

• Confirm input/output signal type before installation
• Verify HART communication requirements
• Check power supply voltage range
• Ensure correct wiring polarity
• Install in a suitable control cabinet environment
