      • Beckhoff EL9187 Potential Distribution Terminal

        Product Type: EtherCAT Potential Distribution Terminal
        Model: EL9187
        Function: 8 × 0 V DC Potential Distribution
        Manufacturer: Beckhoff Automation

        The Beckhoff EL9187 is a passive EtherCAT terminal designed to provide eight 0 V DC connection points for convenient potential distribution. It reduces the need for additional terminal blocks and wiring while passing the power contacts through to adjacent EtherCAT terminals.

        Technical Specifications

        Parameter	Specification
        Model	EL9187
        Product Type	Potential Distribution Terminal
        Number of Outputs	8 × 0 V DC
        Current Load	≤ 10 A
        Nominal Voltage	≤ 60 V DC / ≤ 30 V AC
        Electrical Isolation	500 V (E-bus / field potential)
        Process Image	0 bit
        E-bus Current Consumption	None
        Housing Width	12 mm
        Dimensions	12 × 100 × 68 mm
        Weight	Approx. 50 g
        Mounting	35 mm DIN rail
        Operating Temperature	-25°C to +60°C
        Storage Temperature	-40°C to +85°C
        Protection Rating	IP20
        Approvals	CE, UL, ATEX, IECEx

        Specifications are based on Beckhoff's official product documentation.

        Advantages & Features

        • 8 × 0 V Distribution Points: Provides eight convenient connection points for the common 0 V potential.
        • Space Saving: 12 mm-wide compact design helps reduce control cabinet space.
        • Reduced Wiring: Minimizes the need for separate terminal blocks.
        • Passive Design: No process-image data or EtherCAT configuration is required.
        • Power Contact Pass-Through: The 0 V power contact is connected to the front terminals and passed through to the adjacent terminal.
        • High Current Capacity: Supports up to 10 A current load.
        • Electrical Isolation: Provides 500 V isolation between E-bus and field potential.
        • Industrial Installation: Designed for DIN-rail mounting in EtherCAT control systems.

        Typical Applications

        • Industrial automation
        • EtherCAT I/O systems
        • PLC control cabinets
        • Distributed I/O
        • Machine automation
        • Factory automation
        • Motion control systems
        • Sensor and actuator wiring
        • 24 V DC control systems
        • Industrial control panels

The structure and details of the product：
