      • Beckhoff EL9410 EtherCAT Power Supply Terminal

        Product Type: EtherCAT Power Supply Terminal
        Model: EL9410
        Function: E-bus Power Supply Refresh with Diagnostics
        Manufacturer: Beckhoff Automation

        The Beckhoff EL9410 is an EtherCAT power supply terminal used to refresh and increase the available power on the E-bus in configurations with a large number of EtherCAT terminals. It provides an additional 2 A for the E-bus and can also supply up to 10 A at 24 V DC to the power contacts. Built-in diagnostics are displayed by LEDs and in the process image.

        Technical Specifications

        Parameter	Specification
        Model	EL9410
        Product Type	EtherCAT Power Supply Terminal
        Main Function	E-bus power supply refresh
        Input Voltage	24 V DC (-15% / +20%)
        E-bus Output Voltage	5 V DC
        E-bus Output Current	2 A
        Power Contact Voltage	24 V DC
        Power Contact Current	Max. 10 A
        Electrical Isolation	500 V
        Diagnostics	LED + process image
        Short-Circuit Protection	Yes
        Mounting	35 mm DIN rail
        Protection Rating	IP20
        Operating Temperature	-25°C to +55°C
        Storage Temperature	-40°C to +85°C
        Relative Humidity	95%, non-condensing
        Weight	Approx. 65 g
        Dimensions	Approx. 12 × 100 × 68 mm
        Approvals	CE, UL, ATEX, IECEx, DNV

        Specifications are based on Beckhoff's current product documentation.

        Advantages & Features

        • E-bus Power Refresh: Adds up to 2 A of power to the EtherCAT E-bus for large terminal configurations.
        • Built-In Diagnostics: Provides LED and process-image diagnostics for easier troubleshooting.
        • 24 V Power Contacts: Can provide up to 10 A to downstream power contacts.
        • Electrical Isolation: Provides 500 V isolation between E-bus and field potential.
        • Compact Design: Space-saving EtherCAT terminal housing for DIN-rail installation.
        • Reliable Protection: Short-circuit protection helps improve system reliability.
        • Flexible System Expansion: Allows additional EtherCAT terminals to be installed when the coupler's available E-bus current is insufficient.

        Typical Applications

        • Industrial automation
        • EtherCAT control systems
        • PLC and I/O systems
        • Distributed I/O
        • Machine automation
        • Factory automation
        • Motion control systems
        • Process automation
        • Large EtherCAT terminal configurations
        • Industrial control cabinets

        Important Notes
