        • Beckhoff EL9110 Potential Supply Terminal

          Product Type: EtherCAT Potential Supply Terminal with Diagnostics
          Model: EL9110
          Function: 24 V DC Potential Supply / Power Feed
          Manufacturer: Beckhoff Automation

          The Beckhoff EL9110 is an EtherCAT potential supply terminal designed to create separate 24 V DC potential groups within an EtherCAT terminal system. It feeds 24 V DC through the front terminals and passes the power contacts to adjacent terminals. Built-in diagnostics allow the supply status to be monitored by the EtherCAT coupler.

          Technical Specifications

          Parameter	Specification
          Model	EL9110
          Product Type	Potential Supply Terminal
          Nominal Voltage	24 V DC
          Current Load	≤ 10 A
          E-bus Current Consumption	Typical 90 mA
          Diagnostics	Yes
          Process Image	2 bits
          Power LED	Green
          Electrical Isolation	500 V, E-bus/field potential
          Housing Width	12 mm
          Dimensions	12 × 100 × 68 mm
          Mounting	35 mm DIN rail
          Operating Temperature	-25°C to +60°C
          Storage Temperature	-40°C to +85°C
          Weight	Approx. 50 g
          Wiring	Spring-actuated terminals
          Protection	IP20
          Approvals	CE, UL, ATEX, IECEx, cFMus

          Specifications are based on Beckhoff's official EL9110 documentation.

          Advantages & Features

          • 24 V DC Power Feed: Provides a convenient method for introducing a new 24 V DC potential into an EtherCAT terminal segment.
          • 10 A Current Capacity: Suitable for supplying larger groups of downstream terminals.
          • Built-In Diagnostics: Supply status is transmitted to the EtherCAT coupler for system monitoring.
          • Power LED: Provides quick visual confirmation of the supply voltage.
          • Electrical Isolation: 500 V isolation between E-bus and field potential.
          • Compact Design: Only 12 mm wide, saving valuable control-cabinet space.
          • Easy System Expansion: Allows different potential groups to be established within the same EtherCAT terminal system.

          Typical Applications

          • Industrial automation
          • EtherCAT I/O systems
          • PLC control cabinets
          • Distributed I/O
          • Machine automation
          • Factory automation
          • Motion control systems
          • Process automation
          • 24 V DC sensor and actuator systems
          • Large EtherCAT terminal configurations
