                                              • Beckhoff EL3064 Analog Input Terminal

                                                Product Type: EtherCAT Analog Input Terminal
                                                Model: EL3064
                                                Function: 4-Channel Analog Voltage Input
                                                Manufacturer: Beckhoff Automation

                                                The Beckhoff EL3064 is a 4-channel EtherCAT analog input terminal for measuring 0–10 V voltage signals. It uses 12-bit A/D conversion, single-ended 2-wire inputs and electrically isolated signal transmission, making it suitable for accurate analog measurement in industrial automation systems.

                                                Technical Specifications

                                                Parameter	Specification
                                                Model	EL3064
                                                Product Type	EtherCAT Analog Input Terminal
                                                Number of Inputs	4
                                                Input Type	Single-ended
                                                Signal Range	0–10 V
                                                Resolution	12 bit
                                                Internal Resistance	>130 kΩ
                                                Sampling Type	Multiplex
                                                Input Filter	1 kHz
                                                Conversion Time	Approx. 0.625 ms
                                                Measurement Error	< ±0.3% of full scale at 0–55°C
                                                Electrical Isolation	500 V
                                                E-bus Current	Approx. 130 mA
                                                Distributed Clocks	No
                                                Power Supply	Via E-bus
                                                Process Image	2-byte status + 2-byte value/channel
                                                Operating Temperature	-25°C to +60°C
                                                Protection Rating	IP20
                                                Mounting	35 mm DIN rail
                                                Dimensions	12 × 100 × 68 mm
                                                Weight	Approx. 60 g



                                                Advantages & Features

                                                • 4-Channel Analog Input: Measures four independent 0–10 V signals.
                                                • 12-Bit Resolution: Provides reliable analog signal acquisition.
                                                • High Input Impedance: >130 kΩ minimizes loading of the connected signal source.
                                                • Electrical Isolation: 500 V isolation between E-bus and signal voltage.
                                                • Integrated Filtering: Supports FIR/IIR filtering to reduce signal interference.
                                                • Limit Monitoring: Integrated limit-value monitoring simplifies process supervision.
                                                • Compact Design: Only 12 mm wide, saving valuable control cabinet space.
                                                • Easy EtherCAT Integration: Designed for direct integration into Beckhoff EtherCAT systems.

                                                Typical Applications

                                                • Industrial automation
                                                • PLC control systems
                                                • Process control
                                                • Machine automation
                                                • Sensor signal acquisition
                                                • Pressure and flow monitoring
                                                • Motor and drive control
                                                • HVAC systems
                                                • Factory automation
                                                • Distributed EtherCAT I/O systems

The structure and details of the product：
