                                          • Beckhoff EL1819 Digital Input Terminal

                                            Product Type: EtherCAT Digital Input Terminal
                                            Model: EL1819
                                            Function: 16-Channel Digital Input, 24 V DC
                                            Manufacturer: Beckhoff Automation

                                            The Beckhoff EL1819 is a high-density 16-channel EtherCAT digital input terminal for acquiring binary 24 V DC signals from sensors and field devices. It features a fast 10 µs input filter, 500 V electrical isolation and individual LED status indicators, making it suitable for compact and high-speed industrial automation systems.

                                            Technical Specifications

                                            Parameter	Specification
                                            Model	EL1819
                                            Product Type	EtherCAT Digital Input Terminal
                                            Number of Inputs	16
                                            Input Type	Digital
                                            Connection Technology	1-wire
                                            Nominal Voltage	24 V DC (-15% / +20%)
                                            Signal “0”	-3 to +5 V
                                            Signal “1”	11 to 30 V
                                            Input Current	Typ. 3 mA
                                            Input Filter	Typ. 10 µs
                                            Input Specification	EN 61131-2 Type 1/3
                                            E-bus Current	Approx. 100 mA
                                            Electrical Isolation	500 V
                                            Distributed Clocks	No
                                            Process Image	16 input bits
                                            Power Contact Current	Max. 10 A
                                            Mounting	35 mm DIN rail
                                            Protection Rating	IP20
                                            Operating Temperature	-25°C to +60°C
                                            Storage Temperature	-40°C to +85°C
                                            Dimensions	12 × 100 × 68 mm
                                            Weight	Approx. 65 g

                                            The EL1819 uses a High Density 12 mm housing with 16 connection points and direct plug-in technology for solid conductors.

                                            Advantages & Features

                                            • 16 Digital Inputs: Supports a high number of 24 V DC signals in a very small footprint.
                                            • Fast 10 µs Input Filter: Suitable for fast switching signals and pulse detection.
                                            • High-Density Design: 16 channels in a compact 12 mm-wide terminal.
                                            • Individual LED Indicators: Enables quick visual monitoring of input status.
                                            • 500 V Electrical Isolation: Provides isolation between E-bus and field potential.
                                            • 1-Wire Connection: Simplifies wiring for multi-channel sensors.
                                            • Direct Plug-In Technology: Allows convenient tool-free connection of suitable solid conductors.
                                            • Wide Sensor Compatibility: Suitable for inductive, capacitive and other binary sensors.
                                            • No Address Setting: Designed for straightforward EtherCAT integration.

                                            Typical Applications

                                            • Industrial automation
                                            • PLC control systems
                                            • Factory automation
                                            • Machine automation
                                            • Sensor signal acquisition
                                            • Conveyor systems
                                            • Packaging machinery
                                            • Robotics
                                            • Production lines
                                            • Distributed EtherCAT I/O systems
                                            • High-density control cabinets

The structure and details of the product：
