                                          • Beckhoff EK1100 EtherCAT Coupler

                                            Product Type: EtherCAT Coupler
                                            Model: EK1100
                                            Function: EtherCAT Network Coupling / I/O Bus Coupler
                                            Manufacturer: Beckhoff Automation

                                            The Beckhoff EK1100 connects an EtherCAT network with Beckhoff EL/ES/EM EtherCAT Terminals. It converts 100BASE-TX Ethernet/EtherCAT telegrams into E-bus signals and automatically detects the connected terminals. A typical station consists of the EK1100, connected EtherCAT terminals and an end terminal such as EL9011.

                                            Technical Specifications

                                            Parameter	Specification
                                            Model	EK1100
                                            Product Type	EtherCAT Coupler
                                            Protocol	EtherCAT Device Protocol
                                            Network Interface	2 × RJ45
                                            Transmission Rate	100 Mbit/s
                                            Transmission Standard	100BASE-TX
                                            Maximum Cable Length	100 m
                                            Connected EtherCAT Terminals	Up to 65,534
                                            E-bus Supply	5 V DC / max. 2 A
                                            Supply Voltage	24 V DC (-15% / +20%)
                                            Power Contact Current	Max. 10 A
                                            Propagation Delay	Approx. 1 µs
                                            Electrical Isolation	500 V
                                            Protection Rating	IP20
                                            Mounting	35 mm DIN rail
                                            Operating Temperature	-25°C to +60°C
                                            Storage Temperature	-40°C to +85°C
                                            Dimensions	Approx. 44 × 100 × 68 mm
                                            Configuration	Automatic terminal detection

                                            The EK1100 is Beckhoff's standard EtherCAT coupler for direct connection to an EtherCAT master.

                                            Advantages & Features

                                            • EtherCAT Coupling: Connects Beckhoff EtherCAT I/O terminals directly to the EtherCAT network.
                                            • 2 × RJ45 Interfaces: Supports EtherCAT input and optional downstream connection.
                                            • 100 Mbit/s Communication: Provides fast and deterministic industrial communication.
                                            • Automatic Detection: Connected EtherCAT terminals are automatically detected and represented in the process image.
                                            • Low Latency: Approx. 1 µs propagation delay.
                                            • High Capacity: Supports up to 65,534 EtherCAT terminals in the overall system.
                                            • Integrated E-bus Supply: Provides up to 5 V / 2 A for connected terminals.
                                            • Compact Design: DIN-rail mounting saves control cabinet space.
                                            • Electrical Isolation: 500 V isolation improves system reliability.

                                            Typical Applications

                                            • Industrial automation
                                            • PLC control systems
                                            • Factory automation
                                            • Machine control
                                            • Distributed I/O systems
                                            • Motion control
                                            • Robotics
                                            • Packaging machinery
                                            • Production lines
                                            • Process automation
                                            • EtherCAT-based control cabinets
                                          •

The structure and details of the product：
