                                  • Beckhoff EL1014 Digital Input Terminal

                                    Product Type: EtherCAT Digital Input Terminal
                                    Model: EL1014
                                    Function: 4-Channel Digital Input, 24 V DC
                                    Manufacturer: Beckhoff Automation

                                    The Beckhoff EL1014 is a compact 4-channel EtherCAT digital input terminal designed to acquire binary 24 V DC control signals from sensors and field devices. It features a fast 10 µs input filter, electrical isolation and individual LED status indication for each channel.

                                    Technical Specifications

                                    Parameter	Specification
                                    Model	EL1014
                                    Product Type	EtherCAT Digital Input Terminal
                                    Number of Inputs	4
                                    Input Type	Digital
                                    Connection	2-wire
                                    Nominal Voltage	24 V DC (-15% / +20%)
                                    Signal “0”	-3 to +5 V
                                    Signal “1”	11 to 30 V
                                    Input Current	Typ. 3 mA
                                    Input Filter	Typ. 10 µs
                                    Input Specification	EN 61131-2 Type 1/3
                                    E-bus Current	Approx. 90 mA
                                    Electrical Isolation	500 V
                                    Power Contact Load	Max. 10 A
                                    Diagnostics	LED per channel
                                    Mounting	35 mm DIN rail
                                    Protection Rating	IP20
                                    Operating Temperature	-25°C to +60°C
                                    Storage Temperature	-40°C to +85°C
                                    Dimensions	12 × 100 × 68 mm
                                    Weight	Approx. 50 g
                                    Configuration	No address setting required

                                    Beckhoff specifies four 24 V DC inputs, a typical 10 µs input filter, 500 V electrical isolation and direct connection capability for four 2-wire sensors.

                                    Advantages & Features

                                    • 4 Digital Inputs: Supports four independent 24 V DC signals.
                                    • Fast Response: Typical 10 µs input filtering minimizes signal delay.
                                    • Wide Sensor Compatibility: Suitable for inductive, capacitive and other binary sensors.
                                    • Individual LED Indicators: Provides quick visual confirmation of each input status.
                                    • Electrical Isolation: 500 V isolation between E-bus and field potential.
                                    • Direct Sensor Connection: Additional +24 V terminals simplify connection of 2-wire sensors.
                                    • Compact Design: Only 12 mm wide, saving valuable control cabinet space.
                                    • Easy EtherCAT Integration: Designed for direct integration into Beckhoff EtherCAT systems.

                                    Typical Applications

                                    • Industrial automation
                                    • PLC control systems
                                    • Factory automation
                                    • Machine automation
                                    • Sensor signal acquisition
                                    • Conveyor systems
                                    • Packaging machinery
                                    • Robotics
                                    • Production lines
                                    • Distributed EtherCAT I/O systems

The structure and details of the product：
