AUTOMATIONDIRECT D2-16ND3-2 DirectLOGIC DL205 Digital Input Module

Product Overview

Brand: AutomationDirect
Model: D2-16ND3-2
Product Type: Digital Input Module
Series: DirectLOGIC DL205
Input Type: DC Digital Input
Application: Industrial Automation and PLC Control

The AutomationDirect D2-16ND3-2 is a 16-point DC digital input module for the DirectLOGIC DL205 PLC system. It accepts 24 VDC discrete signals from field devices such as switches, sensors, push buttons, and other control equipment.

The module supports both sinking and sourcing inputs and provides two isolated commons, with 8 input points per common. A removable terminal block is included for convenient wiring and maintenance.

Technical Specifications

Parameter	Specification
Brand	AutomationDirect
Model	D2-16ND3-2
Series	DirectLOGIC DL205
Product Type	Digital Input Module
Number of Inputs	16 points
Input Type	DC Digital
Input Configuration	Sinking / Sourcing
Nominal Input Voltage	24 VDC
Input Voltage Range	20–28 VDC
Peak Voltage	30 VDC
Isolated Commons	2
Points per Common	8
Input Current	6 mA @ 24 VDC
ON Voltage	19 VDC minimum
OFF Voltage	7 VDC maximum
Input Impedance	3.9 kΩ
Minimum ON Current	3.5 mA
Maximum OFF Current	1.5 mA
OFF-to-ON Response	3–9 ms
ON-to-OFF Response	3–9 ms
Base Power Requirement	100 mA max @ 5 VDC
Terminal Block	Removable, included
Weight	Approx. 65 g / 2.3 oz
Country of Origin	Japan
HS Code	8537.10

The specifications above are based on AutomationDirect's product page and technical documentation.

Main Features

16-point 24 VDC digital input module
DirectLOGIC DL205 compatible
Supports sinking and sourcing input configurations
Two isolated input commons
8 input points per common
Input status indicators on the logic side
Removable terminal block included
Compact modular design for PLC systems

Applications

Factory automation
Machine control
Production lines
Conveyor systems
Packaging machinery
Sensor signal monitoring
Industrial equipment control
General PLC-based automation

Product Advantages

Reliable 24 VDC discrete signal acquisition
Flexible sinking/sourcing input configuration
Two isolated input groups provide wiring flexibility
Removable terminal block simplifies installation and maintenance
Compact design saves PLC cabinet space
Suitable for replacement and expansion of DL205 systems

Product Summary

The AUTOMATIONDIRECT D2-16ND3-2 DirectLOGIC DL205 Digital Input Module provides 16 isolated-group 24 VDC discrete inputs for compatible DL205 PLC systems. With sinking/sourcing capability, two isolated commons, and a removable terminal block, it is suitable for industrial machine control and field-signal monitoring applications.

Classification: DirectLOGIC DL205 Digital Input Module / PLC I/O Module

Note: Please verify PLC base compatibility, input wiring configuration, voltage requirements, terminal connections, and system specifications before installation or replacement.
