AUTOMATIONDIRECT D2-09B-1 PLC Base Module

Product Overview

Model: D2-09B-1
Series: DirectLOGIC DL205 PLC
Manufacturer: AutomationDirect

The AUTOMATIONDIRECT D2-09B-1 is a 9-slot PLC I/O Base Module designed for the DirectLOGIC DL205 PLC system. It provides the mounting platform, power distribution, and communication connection for CPU modules and various I/O expansion modules. It supports DIN rail or panel mounting and is widely used in modular industrial automation systems.

Technical Specifications

• Product Type: PLC Base Unit / I/O Rack
• Model: D2-09B-1
• Series: DirectLOGIC DL205
• Number of Slots: 9 slots
  • 1 CPU slot
  • 8 I/O expansion slots
• Power Input: 110–220 VAC external power supply
• Auxiliary Output: 24 VDC isolated output, 300 mA max.
• Internal Power Supply: Provides 5 VDC power for installed modules
• Mounting Type: DIN rail mounting / panel mounting
• Compatible Modules: DirectLOGIC DL205 CPU and I/O modules
• Programming Software: DirectSOFT
• Maximum Power: Approx. 80 VA
• Protection: Industrial PLC-grade design
• Certification: UL / CSA / CE compliant

Advantages & Features

• Modular Expansion Design
  Supports multiple CPU and I/O modules, allowing flexible system configuration.
• Large I/O Capacity
  Provides 9-slot architecture for complex automation applications.
• Reliable Power Distribution
  Built-in power supply distributes stable power to connected PLC modules.
• Flexible Installation
  Supports both DIN rail and panel mounting for easy cabinet integration.
• Easy System Maintenance
  Modular structure allows quick replacement and expansion of components.
• Industrial Reliability
  Designed for continuous operation in factory automation environments.

Applications

• Industrial Automation Systems
• Machine Control Equipment
• Production Line Control
• Packaging Machinery
• Conveyor Systems
• Building Automation
• Process Control Systems
• Manufacturing Equipment

Precautions

• Confirm compatibility with DirectLOGIC DL205 CPU and I/O modules before installation.
• Verify input voltage (110–220 VAC) before powering on.
• Ensure total module power consumption does not exceed base capacity.
• Disconnect power before installing or removing modules.
• Install in a clean, dry control cabinet environment.
• Check wiring and grounding requirements before operation.
