AUTOMATIONDIRECT CM5-T7W Operator Panel

Product Overview

Model: CM5-T7W
Series: C-more CM5 HMI
Manufacturer: AutomationDirect

The AUTOMATIONDIRECT CM5-T7W is a 7-inch color touchscreen Operator Panel (HMI) designed for industrial machine monitoring and control. It provides a graphical interface between operators and PLC systems, allowing users to monitor process data, adjust parameters, display alarms, and control automated equipment.

Technical Specifications

• Product Type: Human Machine Interface (HMI) / Operator Panel
• Model: CM5-T7W
• Series: C-more CM5
• Display Size: 7 inch widescreen TFT LCD
• Display Resolution: 800 × 480 pixels (WVGA)
• Display Colors: 16.7 million colors
• Touch Type: Resistive single-touch screen
• Backlight: LED
• Brightness: Approx. 310 nits
• Project Memory: 45 MB
• Screen Capacity: Up to 999 screens (project dependent)
• Power Supply: 12–24 VDC
• Communication Interfaces:
  • 1 × Ethernet 10/100Base-T (RJ45)
  • 1 × RS-232 (RJ12)
  • 1 × RS-232/422/485 (DB15)
  • 1 × USB Type-A
  • 1 × USB Type-B
  • 1 × SD card slot
• Protection Rating: IP65 / NEMA 4/4X (indoor use)
• Mounting: Panel mounting
• Operating Temperature: 0–50°C
• Compatible Software: C-more Programming Software

Advantages & Features

• Clear Visual Interface
  7-inch high-resolution color touchscreen provides intuitive operation and real-time machine monitoring.
• Flexible Communication
  Supports Ethernet and serial communication for connection with PLCs, drives, and industrial controllers.
• Easy System Integration
  Compatible with many PLC brands and industrial automation devices.
• Rich Display Functions
  Supports alarms, recipes, data monitoring, trends, and graphical objects.
• Compact Industrial Design
  Suitable for control cabinets and machine operator stations.
• Reliable Industrial Operation
  Designed for continuous use in factory automation environments.

Applications

• Industrial Automation Systems
• PLC Operator Interfaces
• Machine Control Panels
• Packaging Machinery
• Production Lines
• Process Monitoring Systems
• Material Handling Equipment
• Factory Automation Equipment

Precautions

• Verify PLC communication protocol compatibility before installation.
• Confirm 12–24VDC power supply requirements.
• Avoid using sharp objects on the resistive touchscreen.
• Install in a clean environment and avoid excessive moisture or dust.
• Use proper shielding for communication cables in high-noise environments.
• Backup HMI projects before replacement or maintenance.
• Ensure correct panel mounting and sealing for IP65 protection.
