Phoenix QUINT-PS/1AC/24DC/5 Industrial Power Supply 24V DC

Phoenix Contact QUINT-PS/1AC/24DC/5 Industrial Power Supply (24V DC, 5A)





The Phoenix Contact QUINT-PS/1AC/24DC/5 is a high-performance industrial switching power supply that converts 1-phase AC input (100–240V AC) into a stable 24V DC output (5A) for industrial automation systems.

It is widely used to power PLC systems, I/O modules, sensors, relays, and industrial controllers.

Key Specifications

• Model: QUINT-PS/1AC/24DC/5
• Order No.: 2866750
• Brand: Phoenix Contact
• Series: QUINT POWER
• Type: Industrial DIN rail power supply
• Input Voltage: 100–240 V AC (1-phase)
• Output Voltage: 24 V DC
• Output Current: 5 A
• Output Power: 120 W
• Efficiency: > 90%
• Mounting: DIN rail (35mm)

Core Functions

This power supply provides:

• Stable 24V DC industrial control power
• Reliable operation for PLC and automation systems
• Short-circuit handling via SFB (Selective Fuse Breaking) technology
• Temporary overload support via POWER BOOST

Key Features & Advantages

• SFB Technology
  • Delivers very high peak current to trip circuit breakers quickly
• POWER BOOST
  • Supplies up to ~7.5A short-term overload capacity
• High efficiency (>90%)
• Adjustable output voltage (18–29.5 V DC)
• Industrial EMC protection and surge resistance
• High reliability for 24/7 operation
• Diagnostic “DC OK” signal output

What it is used for

Typical applications include:

• PLC control cabinets
• Siemens / Allen-Bradley / GE systems
• Industrial automation lines
• Sensors and field devices
• HMI panels
• Motor control circuits (control side only)
