Phoenix IB IL AI 8/IS-PAC Analog Module

Phoenix Contact IB IL AI 8/IS-PAC Analog Input Module (Inline System I/O Module)



The Phoenix Contact IB IL AI 8/IS-PAC is an Inline analog input module used in industrial PLC and automation systems. It belongs to the Phoenix CONTACT Inline I/O system and is designed to collect analog current signals from field devices and send them to a PLC/controller.

Product Information

• Brand: Phoenix Contact (Germany)
• Series: Inline (IB IL series)
• Model: IB IL AI 8/IS-PAC
• Type: Analog input I/O module
• Channels: 8 analog input channels
• Signal type: 0–20 mA, 4–20 mA, ±20 mA (current inputs)
• Function: Signal acquisition (field instruments → PLC system)
• Installation: DIN rail Inline terminal system
• Resolution: 16-bit analog-to-digital conversion

What it actually is

This module is used to read industrial sensor signals, such as:

• Pressure transmitters
• Flow meters
• Temperature transmitters
• Level sensors
• Industrial 4–20 mA devices

It converts these analog signals into digital data for PLC control systems.

It does NOT operate independently.

System Role (Simple)

Field sensors (4–20 mA signals)
→ IB IL AI 8 module (this unit)
→ PLC / controller system
→ control logic execution
→ outputs to machines

So it acts like a “signal acquisition interface between sensors and PLC.”

Key Features

• 8 analog current input channels
• Supports multiple current ranges (0–20 mA / 4–20 mA / ±20 mA etc.)
• 16-bit high-resolution A/D conversion
• High noise immunity and interference suppression
• Short-circuit protected sensor supply
• Individual channel parameter configuration
• Industrial DIN rail modular design

Typical Applications

• Factory automation systems
• PLC control cabinets
• Process monitoring systems
• Water treatment plants
• Oil & gas instrumentation systems
• Machine sensor signal acquisition

Advantages

• High accuracy analog signal reading
• Strong electrical noise resistance
• Flexible channel configuration
• Compact modular Inline design
• Easy integration into PLC systems
• Reliable industrial-grade operation

Important Notes

• Not PLC CPU ❌
• Not controller module ❌
• Not relay module ❌
• Not power module ❌
• It is a PLC I/O analog input module (field signal interface) ✔
• Works only inside Phoenix Contact Inline system architecture

Precautions

• Must be used with compatible Inline bus terminal system
• Requires correct PLC configuration
• Not interchangeable with other brand I/O modules
• Proper shielding required for analog signal cables
• Incorrect wiring may cause signal noise or reading errors
