PHOENIX CONTACT 2810913 Power Supply Module

Product Description

PHOENIX CONTACT 2810913 is not a Power Supply Module. It is an MCR-C-UI-UI-DCI Signal Conditioner (Signal Isolator) used for analog signal conversion and electrical isolation in industrial automation systems.

The module provides 3-way electrical isolation between input, output, and power supply circuits, helping protect control systems from signal interference and ground potential differences. It is commonly used for PLC, DCS, and process instrumentation applications.

Specifications

• Brand: PHOENIX CONTACT
• Model: 2810913
• Product Type: Signal Conditioner / Signal Isolator
• Series: MCR-C-UI-UI-DCI
• Function: Analog Signal Conversion & Isolation
• Number of Channels: 1 Channel
• Power Supply: 18–30 VDC (24VDC nominal)
• Input Signal: Configurable analog input
  • Voltage: 0–10 VDC
  • Current: up to 50 mA
• Output Signal: Configurable analog output
  • Voltage: 0–10 VDC
  • Current: up to 30 mA
• Electrical Isolation: 3-way isolation
• Response Time: Approx. 11 ms
• Mounting: DIN Rail Mount
• Connection: Pluggable screw terminal
• Protection Rating: IP20
• Operating Temperature: -20°C to +65°C
• Width: 17.5 mm

Functions

• Converts industrial analog signals between different signal formats
• Provides galvanic isolation between field devices and controllers
• Protects PLC/DCS systems from electrical interference
• Separates sensor circuits from evaluation circuits
• Improves reliability of analog measurement systems

Advantages & Features

• 3-way electrical isolation design
• Supports common industrial analog signals
• Compact 17.5 mm DIN rail housing
• Reduces signal noise and interference
• Suitable for industrial process applications
• Easy integration into control cabinets

Applications

• PLC analog signal interfaces
• DCS control systems
• Process instrumentation
• Temperature, pressure, and flow measurement systems
• Industrial automation cabinets
• Signal transmission systems

Notes

• 2810913 is a signal conditioner, not a power supply
• Confirm input/output signal type before installation
• Requires 24VDC auxiliary power
• Check wiring configuration before commissioning
• Suitable for standard industrial analog signal isolation applications
