Pepperl+Fuchs MLV12-54-G-7134 Photoelectric Sensor

Product Overview

The Pepperl+Fuchs MLV12-54-G-7134 is a retro-reflective photoelectric sensor designed for industrial automation detection applications. It uses a modulated visible red LED light source (660 nm) to detect objects by measuring reflected light from a reflector. It is suitable for reliable object detection in manufacturing and material handling systems.

The sensor features a compact metal housing, IP67 protection, and M12 connector connection, making it suitable for harsh industrial environments.

Main Specifications

Manufacturer: Pepperl+Fuchs
Model: MLV12-54-G-7134
Product Type:
- Photoelectric Sensor
- Retro-reflective Sensor
- Optical Sensor
Detection Principle: Retro-reflective light barrier
Light Source: Visible red LED
Wavelength: 660 nm
Detection Range: Up to approx. 5.6 m (with suitable reflector)
Operating Voltage: 10–30 VDC
Output Type: PNP switching output
Switching Mode: Light ON / Dark ON selectable
Connection: M12 5-pin connector
Protection Rating: IP67

Technical Specifications

Item	Specification
Housing Width	41.5 mm
Housing Height	49 mm
Housing Depth	15 mm
Operating Voltage	10–30 VDC
Light Type	Modulated red light
Switching Frequency	Up to 1000 Hz
Output Current	Max. 200 mA
Protection Class	IP67
Connection	M12 × 1, 5-pin
Ambient Temperature	-40°C to +60°C
