Pepperl+Fuchs UB5000-F42-UK-V95 Ultrasonic Sensor

Pepperl+Fuchs UB5000-F42-UK-V95 Ultrasonic Sensor

Product Description

The Pepperl+Fuchs UB5000-F42-UK-V95 is an industrial ultrasonic sensor designed for non-contact distance measurement and object detection. It uses ultrasonic waves to detect objects regardless of color, transparency, or surface characteristics. The sensor features a relay output, Teach-In adjustment, temperature compensation, and interference suppression, making it suitable for demanding industrial automation applications.

Technical Specifications

• Brand: Pepperl+Fuchs
• Model: UB5000-F42-UK-V95
• Product Type: Ultrasonic Sensor
• Detection System: Single-head ultrasonic system
• Sensing Range: 350 ... 5000 mm
• Adjustment Range: 400 ... 5000 mm
• Blind Zone: 0 ... 350 mm
• Transducer Frequency: Approx. 65 kHz
• Standard Target Size: 100 × 100 mm
• Response Time: Approx. 650 ms
• Operating Voltage: 22 ... 253 V AC/DC
• Output Type: 1 relay output
• Rated Operating Current: 3 A
• Switching Frequency: ≤ 0.6 Hz
• Repeat Accuracy: ≤ 0.5% of switching point
• Protection Rating: IP65
• Connection: 5-pin V95 connector (7/8"-16 UN)
• Operating Temperature: -25 ... +70 °C
• Housing Material: PBT
• Weight: Approx. 370 g

Advantages & Features

• Non-contact ultrasonic detection technology
• Long detection distance up to 5 meters
• Detects objects independent of color and surface texture
• Relay output suitable for direct switching applications
• Built-in temperature compensation improves measurement stability
• Teach-In function enables easy parameter adjustment
• Adjustable sound cone interference suppression
• IP65 protection for industrial environments

Applications

• Material level detection
• Conveyor system monitoring
• Position detection
• Distance measurement systems
• Packaging machinery
• Automated production lines
• Industrial process control
• Object presence detection

Notes / Precautions

• Ensure the sensing surface is within the specified detection range
• Avoid strong acoustic interference from nearby ultrasonic devices
• Confirm power supply voltage before installation
• Keep the sensor surface clean for stable operation
• Verify relay contact load requirements before connection
