Lenze E84AVBDE2224SX0 Frequency Inverter Drive

Lenze E84AVBDE2224SX0 Frequency Inverter Drive (8400 Series)





The Lenze E84AVBDE2224SX0 is a frequency inverter (VFD) from the Lenze 8400 BaseLine series, used to control the speed, torque, and direction of AC motors in industrial automation systems.

Key Specifications

• Model: E84AVBDE2224SX0
• Brand: Lenze
• Series: 8400 BaseLine
• Product Type: Frequency Inverter / Motor Drive
• Rated Power: 2.2 kW
• Supply Voltage: 3-phase 400–500 VAC
• Output Frequency: 0–599 Hz
• Control Type:
  • Vector control
  • V/f control
• Protection Functions:
  • Overcurrent protection
  • Overvoltage / undervoltage protection
  • Motor thermal protection
• Mounting:
  • Panel / cabinet installation (IP20 class)

Function (Simple Explanation)

This drive is used to control motor speed by changing output frequency:

AC Power (50/60 Hz)
↓
Lenze E84AVBDE2224SX0 (Inverter)
↓
Variable frequency output
↓
AC Motor

So it allows:

• Speed control (slow → fast)
• Smooth start/stop
• Torque regulation
• Energy saving operation

Features & Advantages

• Compact industrial inverter design
• Stable vector control performance
• Wide frequency range up to ~599 Hz
• Integrated motor protection
• Suitable for continuous industrial operation
• Easy integration with PLC systems
• Reliable for conveyor and automation systems

Applications

• Conveyor systems
• Pumps and fans
• Packaging machines
• Textile machines
• General industrial automation
• Light-to-medium duty motor control systems
