LENZE EPL-10200 Drive Controller

Product Description

Detailed Parameters

1. Power & Electrical Specifications
   • Power Range: 0.75kW to 15kW (1.0HP to 20HP).
   • Input Voltage: 3-phase 380-480VAC ±10% (50/60Hz); single-phase 220-240VAC option for 0.75kW-2.2kW models.
   • Output Voltage: 3-phase, 0 to input voltage (proportional to frequency).
   • Output Frequency: 0-500Hz (adjustable via parameters).
   • Rated Output Current: 2.5A to 30A (varies by power rating).
2. Control Capabilities
   • Control Modes:
     • V/f control: For general applications (fans, pumps) requiring basic speed regulation.
     • Sensorless vector control: For dynamic loads (conveyors, mixers) needing stable torque at low speeds.
   • Speed Accuracy: ±0.5% of rated speed (sensorless vector mode).
   • Acceleration/Deceleration Time: 0.1-3600s (configurable).
3. Protection & Safety
   • Built-in Protection: Overcurrent, overload (150% for 60s), overvoltage, undervoltage, overtemperature, short-circuit, and phase loss protection.
   • Efficiency: ≥95% at rated load.
   • Enclosure Rating: IP20 (base model); optional IP65 for dust/water resistance in harsh environments.
4. I/O & Communication
   • Digital Inputs: 4 optically isolated (24VDC, sinking/sourcing configurable) for start/stop, direction, or speed references.
   • Digital Outputs: 2 relay outputs (NO, 250VAC/3A) for status signals or alarms.
   • Analog Input: 1 configurable (0-10V or 4-20mA) for speed/torque references.
   • Communication: Built-in Modbus RTU (RS-485); optional modules for PROFINET or EtherCAT.
5. Environmental & Physical Data
   • Operating Temperature: -10°C to 40°C (no derating); 40°C to 50°C (2.5% derating per °C).
   • Storage Temperature: -25°C to 70°C.
   • Humidity: 5-95% RH (non-condensing).
   • Dimensions: 120mm (W) × 180mm (H) × 150mm (D) (varies by power).
   • Mounting: Vertical panel/flush mount (for optimal heat dissipation).

Key Advantages & Features

1. Cost-Effective Performance
   Balances core drive functions (speed/torque control) with affordability, ideal for budget-focused projects.
2. Flexible Control
   Switches between V/f and sensorless vector modes to adapt to diverse loads (e.g., variable torque for fans, constant torque for conveyors).
3. Compact Design
   Space-saving enclosure fits easily into small control cabinets, perfect for machinery with limited installation space.
4. Easy Commissioning
   Simple parameter setup via keypad or LENZE EASY Starter software (free), reducing setup time for non-specialist users.
5. Robust Protection
   Comprehensive fault protection (overcurrent, overload, etc.) safeguards the drive, motor, and connected equipment, minimizing downtime.

Application Areas

1. Material Handling
   Controls conveyor belts, roller tables, and lifts, matching speed to production flow.
2. Pumps & Fans
   Adjusts speed of centrifugal pumps and axial fans in HVAC or water systems, cutting energy use vs. fixed-speed operation.
3. Light Machinery
   Drives small packaging machines, mixers, and assembly tools, ensuring smooth, consistent operation.
4. Food & Beverage
   Regulates conveyors and agitators in processing lines, with gentle speed transitions to prevent product spillage.
5. Textiles & Printing
   Controls winding machines and rollers, maintaining steady tension for consistent material processing.

Precautions

1. Installation
   • Ensure proper grounding (PE terminal) to prevent electric shock and EMI.
   • Mount vertically with ≥100mm clearance above/below for airflow; avoid heat sources or direct sunlight.
2. Wiring
   • Use shielded cables for motor/control lines; ground shields at the drive end to reduce noise.
   • Select motor cables rated for ≥1.25× the drive’s rated output current.
3. Motor Compatibility
   • Verify motor voltage/power matches the drive; derate by 10% for non-inverter-duty motors.
4. Parameter Setup
   • Set acceleration/deceleration times to match load inertia (slower for high-inertia loads like centrifuges).
   • Configure overload protection to match motor ratings (e.g., 120% for 60s for standard motors).
5. Maintenance
   • Power off before inspecting terminals; clean vents quarterly to prevent dust buildup.
   • Check connections annually (especially in vibrating environments) to avoid loose contacts.
