LENZE EL103ECO HMI Touch Screen

Product Description

Detailed Parameters

1. Display Specifications
   • Screen Size: 7-inch WVGA TFT LCD.
   • Resolution: 800 × 480 pixels, supporting clear visualization of process data and graphical interfaces.
   • Touch Technology: Resistive touchscreen with single-point operation, ensuring reliable input in industrial environments.
   • Brightness: 300 cd/m² for visibility in varying lighting conditions.
2. Hardware Features
   • Processor: 400MHz ARM Cortex-A8 processor for smooth performance in basic HMI tasks.
   • Memory: 64MB DDR3 RAM and 128MB flash storage for program storage and data logging.
   • Connectivity:
     • 1 × Ethernet port (TCP/IP, Modbus TCP, Ethernet/IP).
     • 1 × USB 2.0 host port for peripheral devices (e.g., USB drives, barcode scanners).
     • RS485/RS232 serial port for legacy system integration.
3. Software Compatibility
   • Programming Tool: LENZE L-force Engineer software for intuitive configuration of screens, alarms, and communication protocols.
   • Protocol Support: Modbus RTU, Modbus TCP, Ethernet/IP, CANopen, and PROFIBUS (via optional modules).
4. Environmental Parameters
   • Operating Temperature: 0°C to 50°C (32°F to 122°F).
   • Storage Temperature: -20°C to 70°C (-4°F to 158°F).
   • Humidity: 5-95% RH (non-condensing).
   • Vibration Resistance: 10-57Hz, 0.75mm double amplitude (IEC 60068-2-6).
   • Certifications: CE, UL, and IP65-rated front panel for dust and water resistance.
5. Physical Features
   • Dimensions: 192mm (W) × 138mm (H) × 42mm (D), with a flush-mount design for panel installation.
   • Weight: ~450g.
   • LED Indicators: Power and communication status LEDs for quick diagnostics.

Product Advantages and Features

1. User-Friendly Interface
   • Predefined graphical objects (buttons, gauges, trend charts) simplify screen design and reduce programming time.
   • Multilingual support allows customization for global applications.
2. Flexible Connectivity
   • Multiple communication ports enable seamless integration with PLCs, drives, and other industrial devices.
   • Ethernet-based protocols facilitate remote monitoring and diagnostics via networked systems.
3. Cost-Effective Performance
   • The ECO series balances essential HMI functionality with affordability, making it suitable for budget-sensitive projects.
   • No additional licensing fees for L-force Engineer software.
4. Rugged Design
   • IP65-rated front panel withstands harsh industrial environments (dust, moisture, and oil splashes).
   • Wide temperature range ensures reliable operation in challenging conditions.
5. Data Logging and Alarming
   • Built-in data logging stores process data for analysis and quality control.
   • Configurable alarms with visual and audible alerts enhance system reliability.

Application Areas

1. Machine Automation
   • Controls and monitors packaging machines, conveyors, and assembly lines.
   • Displays real-time production metrics (e.g., speed, downtime) and error messages.
2. HVAC Systems
   • Manages heating, ventilation, and air conditioning parameters in commercial buildings.
   • Provides interface for adjusting setpoints and viewing system status.
3. Material Handling
   • Operates automated storage systems, cranes, and lift gates with intuitive touch controls.
   • Integrates with LENZE drives for coordinated motion control.
4. Energy Management
   • Monitors power consumption and optimizes energy usage in industrial facilities.
   • Displays data from smart meters and energy-efficient equipment.
5. Water/Wastewater Treatment
   • Controls pump operations, valve positions, and filtration processes.
   • Logs historical data for compliance reporting and maintenance scheduling.

Precautions

1. Installation
   • Ensure proper grounding to prevent electrostatic discharge (ESD) damage.
   • Use shielded cables for analog signals to minimize electromagnetic interference.
2. Touchscreen Care
   • Clean the screen with a soft, dry cloth; avoid harsh chemicals or abrasive materials.
   • Resistive touchscreens may require periodic recalibration for accurate input.
3. Software Updates
   • Regularly update firmware to access new features and security patches.
   • Backup project files to prevent data loss during software upgrades.
4. Environmental Limits
   • Avoid exposing the HMI to direct sunlight or extreme temperatures outside the specified range.
   • Install in well-ventilated areas to prevent overheating during continuous operation.
5. Peripheral Compatibility
   • Verify USB device compatibility (e.g., printers, barcode scanners) with LENZE’s hardware specifications.
   • Use high-quality USB cables to ensure stable data transfer.
