LENZE EPL-10200-XX AC Drive Controller

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

LENZE EPL-10200-XX AC Drive Controller

Product Description

Detailed Parameters

1. Power & Voltage Specifications
   • Power Range: 0.75kW to 15kW (1.0HP to 20HP).
   • Input Voltage: 3-phase 380-480VAC ±10%, 50/60Hz (single-phase 220-240VAC option for lower power models).
   • Output Voltage: 3-phase 0-Input Voltage (proportional to frequency).
   • Output Frequency Range: 0-500Hz (adjustable via parameter setting).
   • Rated Output Current: 2.5A to 30A (varies by power rating).
2. Control Modes
   • V/f Control: For general-purpose applications (fans, pumps) requiring simple speed regulation.
   • Sensorless Vector Control: For dynamic loads (conveyors, mixers) needing precise torque at low speeds.
   • Speed Accuracy: ±0.5% of rated speed (sensorless vector mode).
3. Electrical & Protection Features
   • Protection Functions: Overcurrent, overload (150% for 60s), overvoltage, undervoltage, overtemperature, short-circuit, and phase loss protection.
   • Efficiency: ≥95% at rated load.
   • Power Factor: ≥0.9 (at rated output).
4. Communication & I/O
   • Digital Inputs: 4 × optically isolated inputs (24VDC, sinking/sourcing configurable).
   • Digital Outputs: 2 × relay outputs (NO, 250VAC/3A) for status signals or alarms.
   • Analog Inputs: 1 × 0-10V or 4-20mA (configurable) for speed reference.
   • Communication Interface: Built-in Modbus RTU (RS-485); optional fieldbus modules (PROFINET, EtherCAT) available.
5. Environmental & Physical Parameters
   • Operating Temperature: -10°C to 40°C (without derating); 40°C to 50°C (with 2.5% derating per °C).
   • Storage Temperature: -25°C to 70°C.
   • Humidity: 5-95% RH (non-condensing).
   • Protection Class: IP20 (enclosure); IP65 optional for dust/water resistance.
   • Dimensions: 120mm (W) × 180mm (H) × 150mm (D) (varies by power rating).
   • Mounting: Flush or panel mount (vertical orientation recommended for heat dissipation).

Product Advantages and Features

1. Cost-Effective Performance
   • Optimized for budget-sensitive applications, combining core drive functionality (speed/torque control) with minimal unnecessary features.
2. Flexible Control Modes
   • Switches between V/f and sensorless vector control to adapt to diverse loads (e.g., constant torque for conveyors, variable torque for fans).
3. Compact Design
   • Space-saving enclosure fits easily into small control cabinets, ideal for machinery with limited installation space.
4. Easy Commissioning
   • Intuitive parameter setting via keypad or LENZE’s EASY Starter software (free download), reducing setup time for non-expert users.
5. Built-in Protection
   • Comprehensive safety features protect the drive, motor, and connected equipment from faults (e.g., overloads, short circuits), minimizing downtime.

Application Areas

1. Material Handling
   • Controls conveyor belts, roller tables, and lifts, regulating speed to match production flow.
2. Pumps & Fans
   • Adjusts speed of centrifugal pumps and axial fans in HVAC or water treatment systems, reducing energy consumption vs. fixed-speed operation.
3. Packaging Machinery
   • Synchronizes speed of filling machines, labelers, and sealing equipment for consistent product quality.
4. Food & Beverage
   • Drives mixers, agitators, and conveyors in processing lines, with smooth speed transitions to prevent product spillage.
5. Textile & Printing
   • Controls winding machines and textile rollers, maintaining tension via precise torque regulation.

Precautions

1. Installation
   • Ensure proper grounding (PE terminal) to prevent electric shock and electromagnetic interference (EMI).
   • Mount vertically with ≥100mm clearance above/below for airflow; avoid direct sunlight or heat sources.
2. Wiring
   • Use shielded cables for motor and control wiring; ground shields at the drive end to reduce EMI.
   • Select motor cables rated for at least 1.25× the drive’s rated output current.
3. Motor Compatibility
   • Verify motor rating (voltage, power) matches the drive; derate by 10% for inverter-duty motors not specified for variable speed.
4. Parameter Setup
   • Configure acceleration/deceleration times to match load inertia (e.g., longer times for high-inertia loads like centrifuges).
   • Enable overload protection with settings appropriate for the motor (e.g., 120% for 60s for standard motors).
5. Maintenance
   • Power off the drive before inspecting terminals; clean dust from vents quarterly to prevent overheating.
   • Check for loose connections annually, especially in vibrating environment

The structure and details of the product：
