ABB 3BHE032285R0101 High-voltage interface module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3BHE032285R0101 High-Voltage Interface Module is a key interface device for high-voltage control and monitoring systems. It connects high-voltage switchgear to control systems, providing signal isolation, status acquisition, and control output. The module ensures safe electrical isolation, reliable signal transmission, and fast response, enabling secure operation and automation of high-voltage equipment. It is widely used in substations, industrial high-voltage systems, and power control centers.

2. Technical Specifications

3. Key Features & Advantages

• High-voltage electrical isolation: 3 kV isolation between input and output ensures safety

• Fast response: ≤10 ms for rapid control and status acquisition

• Wide compatibility: Works with various PLCs, DCS, and automation systems

• Compact design: DIN rail mount, saves space in control cabinets

• High reliability: Suitable for industrial temperature, humidity, and vibration conditions

• Clear status indication: LED indicators show input/output signal status for easy monitoring

4. Typical Applications

• High-voltage substation monitoring and control

• Industrial high-voltage switchgear interface

• Power plant high-voltage equipment automation

• Distribution automation systems (DAS)

• High-voltage motor control and protection

• Remote monitoring and integration of power systems

5. Installation & Safety Notes

1. Verify wiring: Ensure input and output connections are correct to avoid malfunction or damage.

2. Maintain isolation: The module provides high-voltage isolation; do not disassemble or modify.

3. Environmental conditions: Install in dry, ventilated areas free from dust, moisture, or corrosive gases.

4. Load limitation: Control output current should not exceed 2 A for long-term reliability.

5. Regular inspection: Check terminals and status indicators to ensure stable operation.

6. System integration: Use in conjunction with circuit breakers, contactors, and protective devices in HV systems.
