Lenze MCS 14H32-SRMP1-A24N-ST5S00N-R0SU Servo Motor

Lenze MCS 14H32-SRMP1-A24N-ST5S00N-R0SU Servo Motor





The Lenze MCS 14H32-SRMP1-A24N-ST5S00N-R0SU is a high-performance synchronous servo motor from the Lenze MCS series, designed for precise motion control applications such as robotics, packaging, CNC and automation systems. It works together with Lenze servo drives (like i700 / 8400 systems) to achieve high dynamic positioning and torque control.

Key Specifications

• Model: MCS 14H32-SRMP1-A24N-ST5S00N-R0SU
• Brand: Lenze
• Series: MCS Synchronous Servo Motor
• Rated Power: ~7.1 kW class
• Torque Range: high torque industrial servo class (≈10–100 Nm depending configuration)
• Motor Type: 3-phase synchronous servo motor
• Feedback System:
  • Resolver or encoder (variant dependent)
• Brake:
  • 24V DC holding brake (A24N indicates brake option)
• Cooling:
  • Natural / surface cooled (typical MCS design)
• Mounting:
  • Standard industrial flange (IM B5 style typical)

Function (Simple Explanation)

This is a precision motion motor, which converts electrical energy into controlled mechanical motion:

Servo Drive (Lenze i700 / 8400)
↓
MCS Servo Motor
↓
Mechanical movement (axis / belt / gearbox)

So it provides:

• Precise positioning
• High torque at low speed
• Fast acceleration/deceleration
• Closed-loop motion control

Features & Advantages

• High dynamic response (fast acceleration)
• High overload capacity for industrial duty cycles
• Very accurate positioning with encoder/resolver feedback
• Compact design for machine integration
• Compatible with Lenze i700 / i950 servo drives
• Suitable for geared motor applications
• Industrial-grade durability for 24/7 operation

Applications

• CNC machinery
• Packaging equipment
• Industrial robotics
• Printing machines
• Textile machines
• Automated production lines
• Material handling systems
