Lenze I55AE222F10010002S Servo Motor

Lenze I55AE222F10010002S Servo Motor / Drive Unit (i550 Series)





The Lenze I55AE222F10010002S is actually a Lenze i550 series frequency inverter (servo drive / VFD controller) rather than a standalone servo motor. It is used to control AC motors and servo-like motion systems in industrial automation.

Key Specifications

• Model: I55AE222F10010002S
• Brand: Lenze
• Series: i550
• Product Type: Frequency Inverter / Servo Drive Controller
• Rated Power: ~2.2 kW – 4 kW class (depending configuration)
• Input Voltage: 3-phase 400–480 VAC
• Output: 3-phase variable frequency motor output
• Control Modes:
  • V/f control
  • Sensorless vector control
  • Closed-loop control (with feedback options depending setup)
• Communication:
  • CANopen / fieldbus options (variant dependent)
• Protection Functions:
  • Overvoltage / undervoltage
  • Overcurrent
  • Motor thermal protection
  • Ground fault detection

Function (Simple Explanation)

This unit is used to control motor speed and torque:

PLC / Controller
↓
Lenze I55AE Drive
↓
AC Motor / Servo Motor
↑
(optional feedback encoder)

So it:

• Converts fixed AC power → variable frequency output
• Controls motor speed, torque, and direction
• Acts as the “brain” of motion control system

Features & Advantages

• Compact industrial drive design
• High efficiency motor control
• Stable torque at low speed
• Built-in protection and diagnostics
• Suitable for automation integration
• Supports industrial communication networks
• Easy parameter setting via Lenze tools

Applications

• Conveyor systems
• Packaging machines
• Pumps and fans
• Printing machinery
• Textile equipment
• General industrial automation
