                                                                                                                                                                                                          • GE SELA36AT0030 Circuit Breaker

                                                                                                                                                                                                            Product Overview

                                                                                                                                                                                                            The GE SELA36AT0030 is a Spectra RMS Molded Case Circuit Breaker (MCCB) designed for industrial power distribution and circuit protection applications. It features a solid-state RMS sensing trip unit with adjustable protection functions, providing reliable protection against overload and short-circuit faults.

                                                                                                                                                                                                            ---

                                                                                                                                                                                                            Main Specifications

                                                                                                                                                                                                            • Manufacturer: GE (General Electric) / ABB Electrification
                                                                                                                                                                                                            • Model: SELA36AT0030
                                                                                                                                                                                                            • Series: Spectra RMS
                                                                                                                                                                                                            • Product Type:
                                                                                                                                                                                                              • Molded Case Circuit Breaker (MCCB)
                                                                                                                                                                                                              • Electronic Trip Circuit Breaker
                                                                                                                                                                                                            • Poles: 3 Pole
                                                                                                                                                                                                            • Rated Voltage: 600 VAC
                                                                                                                                                                                                            • Rated Current: 30 A
                                                                                                                                                                                                            • Frame Size: SE150
                                                                                                                                                                                                            • Connection Type: Bolt-On
                                                                                                                                                                                                            • Trip Unit: Solid-State Electronic Trip
                                                                                                                                                                                                            • Protection Function: LSI (Long Time / Short Time / Instantaneous)

                                                                                                                                                                                                            ---

                                                                                                                                                                                                            Technical Specifications

                                                                                                                                                                                                            Item	Specification
                                                                                                                                                                                                            Rated Current	30 A
                                                                                                                                                                                                            Voltage Rating	600 VAC
                                                                                                                                                                                                            Number of Poles	3P
                                                                                                                                                                                                            Frequency	50/60 Hz
                                                                                                                                                                                                            Interrupting Rating	100 kA @ 240 VAC / 65 kA @ 480 VAC / 25 kA @ 600 VAC
                                                                                                                                                                                                            Trip Type	Electronic Solid State
                                                                                                                                                                                                            Mounting	Bolt-On



                                                                                                                                                                                                            ---

                                                                                                                                                                                                            Protection Features

                                                                                                                                                                                                            The SELA36AT0030 provides:

                                                                                                                                                                                                            • Long-time overload protection
                                                                                                                                                                                                            • Adjustable short-time protection
                                                                                                                                                                                                            • Adjustable instantaneous protection
                                                                                                                                                                                                            • RMS current sensing technology
                                                                                                                                                                                                            • Protection for industrial electrical distribution systems



                                                                                                                                                                                                            ---

                                                                                                                                                                                                            Features & Advantages

                                                                                                                                                                                                            • Original GE Spectra RMS series breaker
                                                                                                                                                                                                            • High interrupting capacity
                                                                                                                                                                                                            • Electronic trip technology improves protection accuracy
                                                                                                                                                                                                            • Suitable for demanding industrial environments
                                                                                                                                                                                                            • Compact MCCB design
                                                                                                                                                                                                            • Reliable protection for motors, panels, and power systems
                                                                                                                                                                                                            • Supports replacement and retrofit applications

                                                                                                                                                                                                            ---

                                                                                                                                                                                                            Applications

                                                                                                                                                                                                            Used in:

                                                                                                                                                                                                            • Industrial control panels
                                                                                                                                                                                                            • Factory power distribution
                                                                                                                                                                                                            • Motor control centers (MCC)
                                                                                                                                                                                                            • Manufacturing equipment
                                                                                                                                                                                                            • Commercial electrical systems
                                                                                                                                                                                                            • Energy and infrastructure projects

                                                                                                                                                                                                            Typical applications:

                                                                                                                                                                                                            • Main feeder protection
                                                                                                                                                                                                            • Branch circuit protection
                                                                                                                                                                                                            • Motor and equipment protection
                                                                                                                                                                                                            • Industrial power switching

The structure and details of the product：
