GE IC755CSS12CDA HMI Touch Panel

Product Overview

The GE IC755CSS12CDA is a GE Intelligent Platforms QuickPanel+ Operator Interface (HMI Touch Panel) designed for industrial automation applications. It provides a graphical operator interface for monitoring, controlling, and visualizing industrial processes.

This HMI features a 12.1-inch TFT color display with projected capacitive multi-touch, and is powered by 24 VDC, making it suitable for machine control, PLC interaction, and factory automation systems.

Main Specifications

Manufacturer: GE Intelligent Platforms (now Emerson Automation Solutions)
Model: IC755CSS12CDA
Series: QuickPanel+
Product Type:
- HMI Touch Panel
- Operator Interface Terminal
- Industrial Touchscreen Display
Display Size: 12.1 inch TFT LCD
Resolution: 800 × 600 pixels (SVGA)
Display Color: 65,536 colors
Touch Type: Projected Capacitive Touch
Multi-Touch: Two-point touch
Backlight: LED

Technical Specifications

Processor & Memory

CPU: ARM Cortex-A8 based processor
Processor Frequency: 1 GHz
RAM: 1 GB DDR3 SDRAM
Flash Memory: 512 MB SLC NAND Flash
Operating System: Windows Embedded Compact 7

Communication Interfaces

Supported communication ports:

Ethernet:
- 1 × 10/100Base-T RJ45
Serial Communication:
- 1 × RS-232
- 1 × RS-232/422/485
USB:
- USB 2.0 ports
Storage:
- SD/SDHC card slot

Power Supply

Input Voltage:
- 12/24 VDC ±20%
Maximum Power Consumption:
- Approx. 30 W

Physical Specifications

Item	Specification
Display	12.1" TFT LCD
Resolution	800 × 600 SVGA
Touch Panel	Capacitive Multi-touch
Mounting	Panel Mount
Dimensions	Approx. 314 × 248 × 65 mm
Weight	Approx. 3 kg
