                                            • • GE IC695CHS007 RX3i Universal Backplane

                                                Overview

                                                IC695CHS007 is a compact 7-slot dual-bus universal backplane for Emerson PACSystems RX3i PLC platform (formerly GE Fanuc). It is the smallest rack in the RX3i backplane lineup, engineered for space-limited control cabinets with moderate I/O quantity. The dual-bus architecture supports both new IC695 PCI high-speed modules and legacy IC693/IC694 / Series 90-30 serial I/O modules, allowing mixed new & old hardware deployment to cut system upgrade costs.


                                                IC695CHS007 Backplane



                                                Side View



                                                Specifications

                                                • Total slots: 7 slots with fixed partition rules
                                                  • Slot 0 (leftmost): Exclusive for IC695 series power supply only
                                                  • Slots 1–5: Dual PCI + serial bus, compatible with all RX3i and Series 90-30 modules
                                                  • Slot 6: PCI-only slot, accepts single-width IC695 modules exclusively
                                                • Power input: Isolated 24VDC terminal block on left edge
                                                • Physical size: 265 × 141.5 × 147.3 mm, DIN horizontal mounting
                                                • Environment: Operating temp 0°C ~ +60°C; requires NEMA Type 1 / IP20 cabinet, 102mm clearance on all sides for heat dissipation
                                                • Built-in integrated grounding bar for module shield grounding
                                                • Full hot-swap support for all single-width modules
                                                • No built-in cooling fan, passive heat dissipation design
                                                • Weight: ~1.03 kg

                                                Key Functions

                                                1. Modular mounting carrier

                                                   Installs RX3i CPU, power supply, analog/digital I/O and communication modules in one compact rack for small-scale control systems.
                                                2. Dual-bus signal transmission

                                                   High-speed PCI bus handles modern IC695 modules for fast process data exchange; serial bus retains compatibility with legacy Series 90-30 I/O without full hardware replacement.
                                                3. Central internal power distribution

                                                   Distributes regulated low-voltage power to all inserted modules via backplane traces from external 24VDC power supply.
                                                4. Hot-swap maintenance

                                                   Supports online replacement of faulty I/O or communication modules without shutting down the whole rack, reducing production downtime.
                                                5. System expandability

                                                   Matches IC695LRE001 expansion module to connect extra remote backplanes for larger I/O capacity.
                                                6. Unified grounding suppression

                                                   Integrated grounding bar eliminates common-mode interference and stabilizes analog signal precision in noisy industrial cabinets.

                                                Compatible Equipment

                                                • RX3i CPU, IC695 analog/digital I/O, Ethernet & serial communication modules
                                                • Legacy IC693, IC694 and GE Series 90-30 I/O and option cards
                                                • IC695 series redundant power supply units
                                                • IC695LRE001 serial rack expansion module
                                                • Proficy Machine Edition programming software
                                                • Small-scale turbine auxiliary control peripherals and local SCADA HMI

                                                Applications

                                                Compact industrial control cabinets with limited installation space:
                                                • Small gas/steam turbine auxiliary monitoring racks
                                                • Water & wastewater pump station PLC control panels
                                                • Packaging machinery, factory assembly line automation
                                                • Mini oil & gas wellhead monitoring systems
                                                • Laboratory pharmaceutical batch control equipment
                                                • Small substation secondary distribution control cubicles

The structure and details of the product：
