GE IC694MDL754 Series 90-30 Digital Output Module

Item NO.:
IC694MDL754
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE IC694MDL754 Series 90-30 Digital Output Module

        Product Overview

        Brand: GE Fanuc / Emerson
        Series: PACSystems RX3i
        Model: IC694MDL754
        Product Type: Digital Output Module / Discrete Output Module
        Function: A high-density 32-point DC digital output module used in GE PACSystems RX3i PLC systems. It converts PLC control signals into DC switching outputs for controlling field devices such as relays, solenoid valves, contactors, indicator lamps, and actuators.

        Technical Specifications

        Module Type: Discrete Digital Output Module

        Series Compatibility: GE PACSystems RX3i

        Output Points: 32 points

        Output Groups: 2 isolated groups × 16 channels

        Output Type: Positive Logic (Source Output)

        Rated Voltage: 12/24 VDC

        Output Voltage Range: 10.2–30 VDC

        Output Current:

        0.75 A maximum per point

        External Power Supply: 12–30 VDC

        Output Response Time:

        ON: 0.5 ms maximum

        OFF: 0.5 ms maximum

        Output Voltage Drop: 0.3 VDC maximum

        Isolation:

        Field to backplane: 250 VAC continuous / 1500 VAC for 1 minute

        Group-to-group isolation supported

        Protection Functions:

        Short-circuit protection

        Overcurrent protection

        Overtemperature protection

        Auto recovery function

        Backplane Current Consumption: 300 mA maximum from 5 VDC bus

        Compatible Terminal Blocks:

        IC694TBB032 Box-style terminal block

        IC694TBS032 Spring-style terminal block

        Mounting: RX3i universal backplane installation

        Advantages & Features

        High-Density Output Control

        Provides 32 digital output channels in one module, reducing cabinet space and improving system efficiency.

        Reliable Load Switching

        Supports 12/24 VDC industrial loads such as solenoid valves, relays, contactors, and indicator devices.

        Electronic Protection Design

        Each output channel includes electronic short-circuit, overcurrent, and overtemperature protection, improving system safety and reliability.

        Fast Response Performance

        With a maximum 0.5 ms ON/OFF response time, it is suitable for fast industrial control applications.

        Flexible Group Isolation

        Two isolated output groups allow different voltage supplies or load groups to be controlled independently.

        Easy System Integration

        Designed for GE PACSystems RX3i platforms, providing convenient installation and maintenance.

        Typical Applications

        Industrial PLC control systems

        Factory automation equipment

        Production lines

        Packaging machinery

        Conveyor systems

        Motor starter control

        Solenoid valve control

        Robot automation systems

        Process control applications

        Precautions

        Confirm compatibility with GE PACSystems RX3i before installation.

        Note: IC694MDL754 is designed for RX3i systems and is not compatible with Series 90-30 PLC CPUs.

        Verify output voltage and load current requirements before connection.

        Do not exceed 0.75 A per output point.

        Use proper protection when controlling inductive loads.

        Check terminal block type before installation.

        Disconnect power before replacing the module.

        Verify PLC configuration after installation.
