GE IC694MDL660 Series 90-30 Digital Input Module

Item NO.:
IC694MDL660
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE IC694MDL660 PACSystems RX3i Digital Input Module

        Product Overview

        Brand: GE Fanuc / Emerson
        Series: PACSystems RX3i
        Model: IC694MDL660
        Product Type: Digital Input Module / Discrete Input Module
        Function: A 32-point 24 VDC digital input module designed for GE PACSystems RX3i PLC systems. It collects ON/OFF signals from field devices such as proximity sensors, limit switches, push buttons, and other digital devices, then transfers the input status to the PLC CPU for processing.

        Technical Specifications

        Module Type: Discrete Digital Input Module

        Series: GE PACSystems RX3i

        Input Points: 32 points

        Input Groups: 4 groups × 8 inputs

        Input Type: Positive / Negative Logic Input

        Rated Voltage: 24 VDC

        Input Voltage Range: 0–30 VDC

        Input Current: 7 mA per point (typical)

        ON State Voltage: 11.5–30 VDC

        OFF State Voltage: 0–5 VDC

        Isolation:

        Field to backplane: 250 VAC continuous / 1500 VAC for 1 minute

        Group-to-group isolation supported

        Input Filter Time: Selectable

        0.5 ms

        1 ms

        2 ms

        5 ms

        10 ms

        50 ms

        100 ms

        Response Time: Depends on selected filter setting

        Power Consumption: 300 mA from 5 VDC backplane supply (all inputs ON)

        LED Indicators:

        32 × input status LEDs

        Terminal block status LED

        Terminal Block Compatibility:

        IC694TBB032 Box-style terminal block

        IC694TBS032 Spring-style terminal block

        Mounting: RX3i universal backplane I/O slot installation

        Advantages & Features

        High-Density Digital Input

        Provides 32 digital input channels in one compact module, reducing cabinet space and improving system efficiency.

        Flexible Logic Compatibility

        Supports both positive and negative logic input modes, allowing connection with various industrial sensors and switching devices.

        Fast Signal Processing

        Selectable input filter settings allow users to balance noise suppression and fast response requirements.

        Strong Electrical Isolation

        Provides isolation between field signals and PLC backplane circuits, improving system stability and protecting control equipment.

        Easy Troubleshooting

        Each input channel includes LED status indication, allowing quick monitoring of field signal conditions.

        Reliable Industrial Performance

        Designed for demanding industrial automation environments with stable operation and long service life.

        Typical Applications

        Factory automation systems

        Industrial machinery control

        Production line monitoring

        Sensor signal acquisition

        Packaging equipment

        Material handling systems

        Process automation systems

        Remote I/O control applications

        Manufacturing equipment

        Precautions

        Confirm compatibility with GE PACSystems RX3i CPU before installation.

        Note that this module is designed for RX3i systems and is not compatible with Series 90-30 CPU systems.

        Verify input voltage is within the 0–30 VDC range.

        Check terminal block type before installation.

        Ensure correct wiring polarity for input devices.

        Use proper grounding and shielding in high-noise environments.

        Disconnect power before installing or removing the module.

        Check PLC configuration after replacement.
