                      • Beckhoff EL4132 Analog Output Terminal

                        Product Type: EtherCAT Analog Output Terminal
                        Model: EL4132
                        Function: 2-Channel Analog Voltage Output
                        Manufacturer: Beckhoff Automation

                        The Beckhoff EL4132 is a 2-channel EtherCAT analog output terminal providing -10 to +10 V voltage signals with 16-bit resolution. The outputs are electrically isolated from the E-bus and are suitable for precise control of analog actuators and industrial equipment.

                        Technical Specifications

                        Parameter	Specification
                        Model	EL4132
                        Product Type	EtherCAT Analog Output Terminal
                        Number of Outputs	2
                        Output Signal	-10 to +10 V
                        Resolution	16 bit
                        Output Rate	Max. 15 kS/s
                        Load	>5 kΩ
                        Output Error	< ±0.1% of full scale
                        Distributed Clocks	Yes
                        DC Accuracy	<1 µs
                        Electrical Isolation	500 V
                        E-bus Current	Approx. 170 mA
                        Process Image	2 × 16-bit outputs
                        Power Supply	Via E-bus
                        Operating Temperature	-25°C to +60°C
                        Storage Temperature	-40°C to +85°C
                        Protection Rating	IP20
                        Mounting	35 mm DIN rail
                        Dimensions	Approx. 12 × 100 × 68 mm
                        Weight	Approx. 55 g

                        The EL4132 supports simultaneous 16-bit output conversion, short-circuit-protected outputs and a maximum output rate of 15 kS/s under suitable operating conditions.

                        Advantages & Features

                        • 2-Channel Analog Output: Provides two independent voltage outputs.
                        • 16-Bit Resolution: Enables precise analog control.
                        • Wide Output Range: Supports -10 to +10 V signals.
                        • High-Speed Output: Up to 15 kS/s for dynamic control applications.
                        • Electrical Isolation: 500 V isolation between E-bus and field voltage.
                        • Distributed Clocks: Supports highly accurate synchronization.
                        • Short-Circuit Protection: Improves operational reliability.
                        • Compact Design: 12 mm-wide terminal saves control cabinet space.
                        • Easy EtherCAT Integration: Designed for direct integration into Beckhoff EtherCAT systems.

                        Typical Applications

                        • Industrial automation
                        • PLC control systems
                        • Motion control
                        • Machine tools
                        • Servo and actuator control
                        • Process automation
                        • Factory automation
                        • Robotics
                        • Test and measurement equipment
                        • Industrial control cabinets

The structure and details of the product：
