Beckhoff AX8206-0100-0000 Servo Drive

Beckhoff AX8206-0100-0000 Servo Drive

Product Description

The Beckhoff AX8206-0100-0000 is a dual-axis servo drive module from the AX8000 Multi-Axis Servo System. It integrates inverter technology, EtherCAT communication, and TwinSAFE safety functions to provide precise motion control for synchronous servo motors and asynchronous motors in advanced automation systems.

Technical Specifications

• Brand: Beckhoff
• Model: AX8206-0100-0000
• Product Type: Dual-Axis Servo Drive Module
• Series: AX8000 Multi-Axis Servo System
• Number of Axes: 2 axes
• Rated Output Current: 6 A per channel
• Peak Output Current: 20 A per channel
• DC Link Voltage: Max. 848 V DC
• Power Supply Range: 100–480 V AC
• Communication Interface: EtherCAT
• Drive Profile: CiA402 (IEC 61800-7-201 CoE)
• Feedback System: OCT, EnDat® 3
• Compatible Motors:
  • Synchronous servo motors
  • Asynchronous motors
• Safety Functions:
  • STO (Safe Torque Off)
  • SS1 (Safe Stop 1)
• Safety Standard:
  • EN ISO 13849-1 Category 4 PL e
  • IEC 61508 SIL 3
• Protection Rating: IP20
• Mounting: AX8000 multi-axis system mounting
• Dimensions: Approx. 230 × 60 × 192 mm

Advantages & Features

• Dual-axis design reduces cabinet space requirements
• High-performance servo control with precise positioning
• EtherCAT communication enables fast synchronized motion control
• Integrated TwinSAFE safety functions improve machine safety
• Supports energy exchange through common DC link system
• Compatible with multiple motor types and feedback systems
• Modular AX8000 design simplifies system expansion
• Reliable operation for demanding industrial automation environments

Applications

• CNC machine tools
• Robotics systems
• Packaging machinery
• Semiconductor equipment
• Automated production lines
• Precision positioning systems
• Industrial motion control systems

Notes / Precautions

• Verify compatibility with AX8000 power supply modules before installation
• Confirm motor type and encoder feedback compatibility
• Check EtherCAT communication configuration
• Ensure STO/SS1 safety wiring is correctly connected
• Do not exceed rated current limits
• Commissioning should be performed by qualified technicians
