YASKAWA HV-75AP4 Magnetic Contactor

Product Description

Yaskawa HV-75AP4 is a Magnetic Contactor for Spindle Motor Winding Selection used with Yaskawa Σ-V (Sigma-5) Servo Drive Systems. It is designed to switch spindle motor windings automatically, allowing the servo system to operate efficiently over a wide speed range while maintaining stable torque output. It is commonly installed in CNC machine tools and spindle drive systems.

Note: Although some sellers describe HV-75AP4 as a "Servo Drive," it is not a servo amplifier/drive. It is a magnetic contactor used as a peripheral component for Sigma-5 spindle servo systems.

Technical Parameters

• Brand: Yaskawa
• Model: HV-75AP4
• Product Type: Magnetic Contactor (Winding Selection)
• Application: Sigma-5 Spindle Servo System
• Main Contacts: 3NO + 3NC
• Auxiliary Contact: 1NC
• Rated Insulation Voltage: 600 V
• Rated Continuous Current: 75 A
• 30-Minute Rated Current: 87 A
• Breaking Capacity:
  • 220 VAC: 200 A
  • 440 VAC: 150 A
• Coil Voltage Options:
  • 200 VAC 50/60 Hz
  • 220 VAC 50/60 Hz
  • 230 VAC 60 Hz
• Operating Frequency: Up to 600 operations/hour
• Mechanical Life: 5 million operations
• Applicable Spindle Motor Capacity: 5.5–15 kW (50% ED)
• Operating Temperature: -10°C to +55°C
• Storage Temperature: -20°C to +85°C
• Humidity: 10–95% RH (non-condensing)
• Weight: Approx. 2.5 kg

Advantages & Features

• Original Yaskawa spindle system component
• Designed specifically for Sigma-5 spindle servo applications
• Reliable winding switching for high-speed spindle motors
• High 75 A continuous current rating
• Long mechanical life of 5 million operations
• Heavy-duty industrial construction
• Stable performance in demanding CNC environments
• Easy integration with Yaskawa spindle drive systems

Applications

• CNC machining centers
• CNC lathes
• Milling machines
• Grinding machines
• High-speed spindle systems
• Machine tool automation
• Industrial servo spindle control

Notes

• HV-75AP4 is a magnetic contactor, not a servo drive or servo amplifier.
• Verify the coil voltage and spindle system compatibility before installation.
• Install according to Yaskawa Sigma-5 wiring requirements.
•
