YASKAWA HV-75AP4/UL Magnetic Contactor

Product Overview

The YASKAWA HV-75AP4/UL is a magnetic contactor designed for industrial motor control and power switching applications. It is part of Yaskawa’s HV series, featuring high durability, low power consumption, and UL certification for safety compliance. This contactor is widely used in automation, HVAC systems, and heavy machinery due to its reliable performance under high electrical loads .

Key Features & Technical Specifications

1. Electrical Performance

• Rated Current: 75A (AC-3 duty at 400V)

• Voltage Rating:

  • Control Voltage: 24V DC / 110–240V AC

  • Main Circuit Voltage: Up to 690V AC

• Switching Capacity: 45 kW (400V AC, AC-3)

• Mechanical Life: 10 million operations

• Electrical Life: 500,000 operations (AC-3)

2. Construction & Protection

• Contact Material: Silver alloy (AgSnO₂) for high arc resistance

• Enclosure: IP20 (dust-resistant, for panel mounting)

• Terminals: Screw-type for secure wiring

3. Safety & Compliance

• Certifications: UL, CE, IEC 60947-4-1

• Protection Features:

  • Overload and short-circuit protection (when used with thermal relays)

  • Arc chutes for efficient arc extinguishing

4. Environmental Specs

• Operating Temperature: -25°C to +60°C

• Humidity Tolerance: ≤95% RH (non-condensing)

Applications

1. Motor Control:

   • Three-phase induction motors in industrial pumps, fans, and compressors .

2. HVAC Systems:

   • Power switching for air handlers and chillers.

3. Material Handling:

   • Conveyors, cranes, and hoists requiring frequent switching .

Installation & Usage Notes

1. Wiring:

   • Use shielded cables for noise-sensitive applications.

2. Maintenance:

   • Regularly inspect contact wear and arc chute condition.

3. Compatibility:

   • Pairs with Yaskawa thermal overload relays (e.g., TH-T series) for complete motor protection.

The structure and details of the product：
