YASKAWA JAMSC-B1064 I/O Module

Product Description

Detailed Parameters

1. I/O Configuration
   • Digital Inputs: 16 channels (sinking/sourcing configurable).
   • Digital Outputs: 16 channels (transistor output, 0.5A/channel).
   • Input Voltage: 24VDC ±10% (common power supply for inputs).
   • Output Voltage: 24VDC ±10% (external power required for outputs).
2. Communication Interface
   • Fieldbus Support: Built-in SSCNETⅢ/H (YASKAWA’s high-speed servo network) for seamless integration with Sigma-7/Sigma-5 drives.
   • Cycle Time: ≤0.5ms (depends on system configuration).
   • Synchronization: Real-time synchronization with servo drives for precise motion control.
3. Electrical Characteristics
   • Input Impedance: ~3.3kΩ per channel.
   • Output Saturation Voltage: ≤1.5V at 0.5A.
   • Isolation: Optocoupler isolation between inputs/outputs and communication interface.
   • Power Consumption: ≤5W (excluding output load).
4. Environmental Parameters
   • Operating Temperature: 0°C to 55°C (32°F to 131°F).
   • Storage Temperature: -20°C to 70°C (-4°F to 158°F).
   • Humidity: 10-90% RH (non-condensing).
   • Vibration Resistance: 10-55Hz, 0.75mm double amplitude (IEC 60068-2-6).
   • Shock Resistance: 10g (IEC 60068-2-27).
5. Physical Features
   • Dimensions: 125mm (W) × 90mm (H) × 75mm (D).
   • Weight: ~300g.
   • Mounting: DIN rail or panel mount.
   • Terminals: Screw terminals (M3) for secure wiring.

Product Advantages and Features

1. High-Speed Communication
   SSCNETⅢ/H protocol enables ultra-fast data transfer (up to 150Mbps), reducing latency in multi-axis systems.
2. Flexible I/O Configuration
   Configurable sinking/sourcing inputs and high-current transistor outputs simplify integration with diverse industrial devices.
3. Modular Design
   Compact form factor allows dense mounting in control panels, optimizing space utilization.
4. Real-Time Synchronization
   Ensures precise timing between servo drives and I/O signals, critical for synchronized motion in robotics and CNC machinery.
5. Diagnostic Capabilities
   Built-in LED indicators for power, communication status, and I/O channel activity facilitate quick troubleshooting.

Application Areas

1. Industrial Robotics
   Controls grippers, sensors, and auxiliary equipment in robotic arms for assembly, welding, and material handling.
2. CNC Machine Tools
   Manages tool changers, coolant valves, and safety interlocks in milling, turning, and grinding machines.
3. Packaging Machinery
   Coordinates conveyors, labeling systems, and sealing mechanisms with servo-driven axes.
4. Material Handling Systems
   Integrates with sensors and actuators in automated storage and retrieval systems (AS/RS).
5. Automated Production Lines
   Provides I/O expansion for PLCs and servo systems in high-speed manufacturing processes.

Precautions

1. Wiring
   • Use shielded cables for communication lines to minimize electromagnetic interference (EMI).
   • Separate power and signal wiring to prevent noise coupling.
2. Power Supply
   • Ensure stable 24VDC power for inputs and outputs; use a dedicated power supply for outputs to avoid voltage drops.
3. Environmental Protection
   • Avoid installation in areas exposed to moisture, dust, or corrosive substances.
   • Use appropriate enclosures for harsh environments (e.g., IP65-rated cabinets).
4. Software Configuration
   • Configure I/O addresses and parameters using YASKAWA’s SigmaWin+ software for seamless integration with servo drives.
5. Maintenance
   • Periodically inspect terminals for tightness and signs of corrosion.
   • Replace damaged components promptly to maintain system reliability.
