YASKAWA GA50C4005EBA AC Drive Inverter

Product Description

Yaskawa GA50C4005EBA is a GA500 Series AC Micro Drive (Variable Frequency Drive, VFD) designed for industrial motor speed control applications. It provides precise speed, torque, and process control for induction motors, permanent magnet (PM) motors, and synchronous reluctance motors. The compact design and advanced control functions make it suitable for a wide range of industrial automation and machinery applications.

The GA500 series features built-in EMC filtering, flexible communication options, simple commissioning, and high-performance motor control, making it ideal for conveyors, pumps, fans, mixers, packaging machines, and general industrial equipment.

Technical Parameters

• Brand: Yaskawa
• Model: GA50C4005EBA
• Series: GA500
• Product Type: AC Drive / Variable Frequency Drive (VFD)
• Input Power Supply: Three-phase 380–480 VAC (400 V class)
• Rated Output Current:
  • Heavy Duty (HD): 4.8 A
  • Normal Duty (ND): 5.4 A
• Overload Capacity:
  • HD: 150% for 60 seconds
  • ND: 110% for 60 seconds
• Motor Compatibility:
  • Induction motors
  • Permanent magnet (PM) motors
  • Synchronous reluctance motors
• Control Modes:
  • V/f Control
  • Open Loop Vector Control
  • PM Motor Control
• Frequency Range: 0–590 Hz
• Protection Functions:
  • Overcurrent
  • Overvoltage
  • Undervoltage
  • Overload
  • Overtemperature
  • Ground fault protection
• Safety Function: Safe Torque Off (STO), SIL3 / PLe capable
• Communication Options:
  • EtherNet/IP
  • PROFINET
  • EtherCAT
  • Modbus/TCP
  • PROFIBUS
  • DeviceNet
  • CC-Link (optional communication cards)
• Mounting: Panel / Control Cabinet
• Cooling: Forced-air cooling
• Protection Rating: IP20 (standard)
• Operating Temperature: -10°C to +50°C (without derating)

Advantages & Features

• Original Yaskawa GA500 industrial AC drive
• Compact, space-saving design
• High-performance motor control for multiple motor types
• Easy commissioning without motor auto-tuning in many applications
• Built-in Safe Torque Off (STO) safety function
• Supports numerous industrial communication protocols
• High overload capability for demanding applications
• Energy-saving operation with precise speed regulation
• Reliable performance and long service life in industrial environments

Applications

• Conveyor systems
• Pumps
• Fans and blowers
• Mixers and agitators
• Packaging machinery
• Material handling equipment
• Textile machinery
• Food & beverage processing
• General industrial automation
• OEM machine control

Notes

• Confirm the 400 V power supply and motor current match the drive specifications before installation.
• Select the appropriate optional communication card if industrial network connectivity is required.
• Configure motor parameters before commissioning to achieve optimal performance.
• Installation should comply with Yaskawa wiring, grounding, and cooling requirements.
