PHOENIX MINI-MCR-SL-UI-UI-NC-2864150 Signal Conditioner

PHOENIX CONTACT MINI MCR-SL-UI-UI-NC 2864150 Signal Conditioner

Product Overview

The PHOENIX CONTACT MINI MCR-SL-UI-UI-NC (2864150) is a compact analog signal conditioner / isolating amplifier designed for industrial automation systems. It provides signal conversion, amplification, filtering, and electrical isolation for standard analog signals.

Main Specifications

• Manufacturer: PHOENIX CONTACT
• Model: MINI MCR-SL-UI-UI-NC
• Part Number: 2864150
• Product Type: Signal Conditioner / Signal Isolator
• Series: MINI Analog
• Channels: 1 Channel
• Power Supply: 24 V DC
• Configuration: DIP Switch Adjustable
• Isolation: 3-way electrical isolation
• Input Signal:
  • 0–10 V
  • 0–5 V
  • 1–5 V
  • 2–10 V
  • 0–20 mA
  • 4–20 mA
• Output Signal:
  • 0–10 V
  • 0–5 V
  • 1–5 V
  • 2–10 V
  • 0–20 mA
  • 4–20 mA
• Mounting: DIN Rail Mount
• Dimensions: 6.2 × 93.1 × 101.2 mm
• Operating Temperature: -20°C to +65°C

Advantages & Features

• Provides reliable electrical isolation between circuits
• Supports flexible voltage and current signal conversion
• Compact 6.2 mm housing saves cabinet space
• DIP switch configuration for easy adjustment
• High signal accuracy and stable transmission
• Reduces signal interference in industrial environments

Applications

• PLC analog signal processing
• Industrial automation systems
• Process control equipment
• Measurement and monitoring systems
• Factory control cabinets
• Energy and manufacturing industries

Important Notes

• Confirm input/output signal range before installation
• Use correct 24VDC power supply
• Ensure proper DIN rail installation and wiring
• Avoid moisture, dust, and strong vibration environments
• Disconnect power before maintenance
