PHOENIX 2901538 RAD-AO4-IFS Analog Output Module

Product Description

PHOENIX CONTACT 2901538 RAD-AO4-IFS is a Radioline Analog I/O Extension Module designed for industrial automation systems. It provides four analog current or voltage outputs for remote signal control and integration with PLC and process control systems.

Specifications

• Brand: PHOENIX CONTACT
• Model: 2901538
• Product Type: Analog Output Module / I/O Extension Module
• Series: Radioline
• Analog Outputs: 4 channels
• Output Signal:
  • 0/4–20 mA
  • 0–10 VDC
• Resolution: 16 bit
• Accuracy: ≤0.02% (at 25°C)
• Supply Voltage: 19.2–30.5VDC
• Current Consumption: ≤115 mA @ 24VDC
• Mounting: DIN rail mounting
• Protection Class: IP20
• Operating Temperature: -40°C to +70°C
• Connection: Screw terminal connection

Advantages & Features

• Supports both current and voltage analog output signals
• High 16-bit resolution for accurate signal control
• Electrical isolation improves system stability and safety
• Compact DIN-rail design saves cabinet space
• Suitable for harsh industrial environments
• Supports flexible remote I/O expansion
• Built-in surge protection for reliable operation

Applications

• Industrial automation systems
• PLC remote I/O networks
• Process control systems
• Factory production lines
• Pump and motor control
• Instrumentation and monitoring systems
• Energy and building automation

Notes

• Confirm compatibility with Radioline system components before installation
• Check output signal type (0–10V / 4–20mA) before wiring
• Ensure correct 24VDC power supply connection
• Use shielded cables for analog signal transmission when required
• Installation should follow industrial electrical standards
