PHOENIX 2832593 FL SWITCH SF 14TX/2FX Ethernet Switch

Product Description

The PHOENIX CONTACT 2832593 FL SWITCH SF 14TX/2FX is an Industrial Ethernet Unmanaged Switch designed for reliable communication in industrial automation networks. It provides 14 × RJ45 Ethernet ports and 2 × fiber optic ports, allowing flexible network expansion through copper and fiber connections.

The switch supports 10/100 Mbps Ethernet communication, automatic speed detection, auto negotiation, and autocrossing functions. It is suitable for connecting PLCs, HMIs, industrial PCs, remote I/O stations, and other Ethernet-based automation devices.

Detailed Specifications

Parameter	Specification
Manufacturer	PHOENIX CONTACT
Model	2832593
Product Type	Industrial Ethernet Switch
Series	FL SWITCH SF
Switch Type	Unmanaged Switch
Ethernet Ports	14 × RJ45
Fiber Ports	2 × SC Multimode Fiber
Ethernet Speed	10/100 Mbps
Fiber Speed	100 Mbps Full Duplex
Fiber Wavelength	1300 nm
Fiber Transmission Distance	Up to 6400 m (depending on fiber type)
Supply Voltage	24 VDC redundant
Voltage Range	18.5–30.2 VDC
Power Consumption	Approx. 246 mA at 24 VDC
Mounting	DIN Rail Mount
Protection Rating	IP20
Housing Material	Aluminum
Operating Temperature	0°C to +55°C
Dimensions	205 × 115.3 × 30 mm
Weight	Approx. 384 g
Communication Standard	IEEE 802.3

Advantages & Features

Industrial-grade unmanaged Ethernet switch
Supports both copper Ethernet and fiber optic communication
14 RJ45 ports for large-scale device connections
2 SC fiber ports for long-distance network transmission
Automatic speed detection and auto configuration
Supports redundant 24 VDC power supply
LED indicators for:
- Power status
- Link/activity status
- Data transmission speed
Store-and-forward switching technology
DIN rail installation for control cabinets
High reliability for continuous industrial operation
