PEPPERL+FUCHS OBR4000-18GM60-E5-V1-1C Photoelectric Sensor

Item NO.:
OBR4000-18GM60-E5-V1
Payment:
T/T
Price:
$295
Product Origin:
CHINA
Color:
NEW
Product weight:
0.02KG
Lead Time:
In stock

PEPPERL+FUCHS OBR4000-18GM60-E5-V1-1C Photoelectric Sensor

The PEPPERL+FUCHS OBR4000-18GM60-E5-V1-1C is an M18 retroreflective photoelectric sensor designed for reliable object detection up to 4 m. It uses a modulated visible red LED, polarization filter, and a robust nickel-plated brass housing.

Key Technical Specifications

Specification	Details
Brand	Pepperl+Fuchs
Model	OBR4000-18GM60-E5-V1-1C
Product Type	Retroreflective Photoelectric Sensor
Sensing Method	Retroreflective
Effective Detection Range	0–4 m
Threshold Detection Range	4.5 m
Reference Reflector	H50
Light Source	LED
Light Type	Modulated visible red light
Polarization Filter	Yes
Operating Voltage	10–30 VDC
Output	1 PNP output
Output Protection	Short-circuit and reverse-polarity protected
Max. Switching Voltage	30 VDC
Max. Switching Current	100 mA, resistive load
Switching Frequency	500 Hz
Response Time	≤1 ms
Light/Dark Switching	Electronically selectable
Housing	Nickel-plated brass
Housing Design	Cylindrical M18 × 1
Connection	4-pin M12 × 1 connector
Protection Rating	IP67
Operating Temperature	-40 to +60 °C
Dimensions	Approx. Ø18 × 65.1 mm
Weight	Approx. 23 g

Specifications are from the Pepperl+Fuchs product page and datasheet.

Advantages & Features

4 m detection range for long-distance object detection.
Modulated visible red LED for stable optical detection.
Integrated polarization filter improves detection reliability with reflective targets.
Fast ≤1 ms response time and 500 Hz switching frequency.
Robust M18 nickel-plated brass housing.
IP67 protection for demanding industrial environments.
PNP output with short-circuit and reverse-polarity protection.
Electronic light-on/dark-on switching selection.
